LED Outdoor Screen Hire for Stage , Commercial P10 P16 P8 Rent Video Wall Displays

Specifications

Brand Name :

kaixin

Model Number :

LM-R6

Certification :

UL CE ROHS ISO ETL SGS SAA Fcc EMC

Place of Origin :

China

MOQ :

1 Square Meter

Price :

Negotiation

Payment Terms :

Western Union, MoneyGram, T/T VISA

Supply Ability :

5,000 square meters per month

Packaging Details :

Packaging Details : Wooden box or Flight case Piexl density : P5.2mm/ 6.944mm/7.8125mm/8.92mm LED : 1R1G1B Cabinet Dimension : 1000 * 500 mm, 500mm x 1000mm Refresh Rate(Hz) : ≥ 1800 Scan method : 1/16 Brightness : >1800cd/sqm Working Voltage : AC 220+/- 1

Description

LED Outdoor Screen Hire for Stage , Commercial P10 P16 P8 Rent Video Wall Displays

Product Description:

P8 are the light-weight and super-thin led display screens, which are very suitable for video rental businesses and large square applications. Jointed correctly, easy to install and dismount, simple structures are the main features of the screens.

P8 is the best choice for creative designing company to achieve large square video show.

Main Features:

1. Light-weight. Convenient in transporting and installing & saving labor cost, suitable for flow shows.

2. Nice appearance and simple structures.

3. Jointed correctly, being installed & dismounted by one person without tool.

4. Humanized operating interface with breakdown indicator lights, easy to maintain.

5. High debugging brightness and no damage to gray scale, achieving the debugging technology for nice image.

Technological Parameters:

Outdoor SMD 3 in 1Die-cast aluminum full color LED Display
Pitch/mm	P6	P6.25	P8	P10
Module size/mm	288x288	250x250	320x320	320x320
Density of pixel/(dots/m2)	27,777	25,600	15,625	10,000
Pixel composition	1R1G1B	1R1G1B	1R1G1B	1R1G1B
Led encapsulation	SMD3535	SMD3535	SMD3535	SMD3535
Resolution of module	48X48	40X40	40X40	32X32
Optimum viewing distance	6-16m	6.25-16.25m	8-20m	10-25m
View angle / °	160 H,120 V	160 H,120 V	160 H,120 V	160 H,120 V
Size of cabinet/mm	576x576	500x500	640x640	640x640
Resolution of cabinet	96X96	80X80	80x80	64X64
Weight of cabinet/kg	9.5	8.9	13	13.8
Driving method	1/4 scan	1/4 scan	1/4 scan	1/4 scan
Refresh rate Hz/S	≥600	≥600	≥600	≥600
Luminance of white balance	≥5500	≥5500	≥5500	≥5500
Operation Temperature/°C	below 30 to above 50
Working vlotage	110-220 VAC/+/- 10%
Grey scale/color	displaying colors≥16.7M(synchronized)
Brightness adjustment	256 levels of each color(manually),100 levels of each color(automatically)
Input signal	RF,S-Video,RGB,RGBH,YUV,YC&Composition ,etc
Control system	linsn(sending card,receiving cards and Hubs)
Average of non-failure life	>50,00h
Life span	>100,000h
Functionaless dot rate	<0.0001

1. Super slim
2. Super light
3. Easy to cary,to transport
4. Very stable ,no deformation
5. With fanless power supply,no noise
