Ultra Thin SMD LED Display , Outdoor / Indoor Full Color Stadium LED Screen
Specifications
High flatness: using CNC cabinet,the cabinet flatness ≤0.1mm
Easy installation: with steel structure, easy to assemble and maintain
Play effect: bright color, high contrast, show natural signal
Large area splicing: play HD video and advertisements, waterproof, wide view angle, UV proof
Low light decay: constant-current driving, with annual light decay ≤20%, long life span
Main Features
1. Perfect Display Effect
High brightness and clearly display effect with easy use control system which allow you easily become enviable led display experts.
2. Attractive Factory Price
We are a professional manufacturer, has its own factories and production lines. Our price is more competitive, quality is more reliable.
3. Good After-sale Service
We offer a 1-3 year warranty service, and to provide free technical guidance. We have a professional service team; they are always online waiting to serve you.
4. CE, ISO 9001, ISO 14001 Certification
All our products have CE, ISO 9001 and ISO 14001 certification. Meet most countries request on import. According to the customer's requirements, we also could provide the certificate of origin.
Product Description:
Pixel Pitch | 8mm |
Pixel configuration | 3in1 |
Pixel density | 15625dot/sq.m |
Module size | 256*128*20mm |
Module resolution | 32*16 |
Module weight | 0.263kg |
LED lamp | SMD3535 |
Scanning | 1/4scan |
Brightness | 5000-5500cd/sq.m |
Refresh rate | more than1920Hz |
Max power consumption | 880W/sq.m |
Average power consumption | 350Wsq.m |
Viewing angle | H:140° V:140° |
Viewing distance | more than8m |
Screen weight | 32kg/sq.m |
Flatness | ±0.25mm |
Installation method | Stacking/hanging |
Control method | synchronous/asynchronous |
Our service
1. Your inquiry related to our products or price will be replied in 24 hrs
2. OEM ODM,and your customized lightings we can help you to design and put into product
3. Protection of your sales area,ideas of design and all your private information
4. Top Quality+Reasonable Price+Responsible After Service=Successful & Win
5. Produce all kinds of Pitch: P4.75,P6.0, P7.62, P10, P12, P16, P20, P25, P31.25...,
6. We offer a 1-3 year warranty service according different order, and to provide free technical guidance. We have a professional service team; they are always online waiting to serve you. During the warranty period, all damaged parts could be replaced free of charge.
Pixel Picth | 8mm |
Configuration | 1R1G1B |
Module size | 128*256mm |
Resolution | 15625dots/sqm |
Standard cabinet size | 768*768mm |
Cabinet weight | About 29KG |
Cabinet material | Iron or Aluminum |
Ave. Consumption | 800 w/sqm |
Max. Consumption | ≤1200 w/sqn |
Brightness | More than 5500cd/sqm |
Grey Scale | 4096 |
View Distance | 8-100 m |
View Angle | Horizontal: 120°, Vertical: 120° |
Power Supply | AC 110V/220V+-10% |
Drive Mode | 1/4Scan |
Refresh Rate | >1000 Hz/s |
Control System | LINSN/NOVA |
Tolerance between modules | ≤1.5mm |
Storage Temperature | - 35°C ~ + 85°C |
Working Temperature | - 20°C ~ + 65°C |
Signal Interface | DVI |
MTBF | ≥10,000 hours |
Life span | ≥100,000 hours |
Operation Humidity | 10% ~ 95% |
Waterproof Grade | Front: IP65, Rear:54 |
Input source | DVI, S-video, RGB, VGA and etc |
Operation System | Windows98, 2000, ME, VISTA, XP, Win7 |
Certifications | CE, CCC, ROHS, ISO9001 |
