Background Stage LED Display High Resolution SMD with Anti UV Plastic IP65 P8 Rental

Specifications

Brand Name :

kaixin

Model Number :

LM-P6.67 SMD RGB

Certification :

UL CE ROHS ISO ETL SGS SAA Fcc EMC

Place of Origin :

China

MOQ :

1 Square Meter

Price :

Negotiation

Payment Terms :

Western Union, MoneyGram, T/T VISA

Supply Ability :

5,000 square meter per month

Packaging Details :

Packaging Details : Wooden box or Flight case Screen Dimension : 1000mmx500mm LED type : RGB 3in1 SMD3528 working voltage : AC 110/220V working temp : -20℃ to +60℃ Viewing angle : 140H,120V lifetime : 100,000 hours Protection : IP65 / IP54 Tube Chip Color

Description

Background Stage LED Display High Resolution SMD with Anti UV Plastic IP65 P8 Rental

Function and Technology Character
1. Light ,suitable for flow shows ,conveninet in transporting and jointing .

2. Nice appearance and secure

3. Joined correctly, could be dismounted by one person without tool .

4. Humanized operating interface with breakdown indicator lights

5. Hight brighness and no damage to gray scale , matched well with the debugging technology with nice image

Application Scene: ideal for dazzling different events, such as stage, concert, fashion show, wedding, conference, building, hotel, club & bars, festival, etc.

SPECIFICATIONS Parameters:

Color type	Real full color
Module size	320*320mm
Pixel led	SMD3528
Resolution rate	48*48
Driving IC	MBI5024
Working voltage	DC5V
Power	120W
Working temperature	-30°C - +50°C
Pixel pitch	6.67mm
Pixel configuration	1R1G1B
Cabinet resolution	96*96
Scanning method	Constant current driver
Work method	1/8 duty
Mask	yes
Dot density	22477/m2
Brightness	1500-1800CD/m2
Color temperature	6500K—8000K
Best viewing distance	5m---70m
Gray Grade	16bit
Display color	102410241024
Refresh frequency	400-1680Hz
Supply voltage	5V
Rated power	600W/ cabinet
Average power	300W/ cabinet
Control system	LINSN
Receiving card load method	One cabinet one card
Material	Anti-UV plastic suite
IP level	IP31
Weight	12KG/cabinet
Cabinet size	64064064mm

Indoor SMD Rental model: PH4, PH5, PH6, PH7.62, PH8, PH10, PH12, PH16, PH20, PH25, PH31.25,PH40.....
Outdoor DIP Rental model: PH10, PH12, PH14, PH16, PH20, PH22, PH25, PH31.25, PH40, PH50, PH70......

Outdoor SMD Rental model: PH6, PH8, PH10, PH12, PH14, PH16, PH18, PH20, PH25, PH31.25.....

LED SMD soft 360 degree transparent Rental curtain screen

LED SMD flexible transparent curtain Renatal display screen

LED DIP/SMD gridding background stage Rental screen

LED DIP/SMD Strip transparent Rental curtain screen

LED DIP/SMD mesh transparent Rental curtain screen

OEM ODM service is acceptable

Pixel Pitch	8mm
Panel Size	1024mm*1024mm
Pixel Density	15625/m2
Pixel Configuration	1R1PG1B
Panel Resolution (pixel)	128*128
Pixel Number/Panel	5
Weight of Panel	58kg/m2
Viewing Distance	15-300m
White Balanced Brightness	≥7000cd/m2
Power Consumption (average)	300W/m2
Power Consumption (max.)	≤1000W/m2
Control Mode	Synchronization
Drive Mode	driven by static and constant current
