Programmable P6 LED Display Project , SMD 3535 RGB Advertising LED Wall Rental

Specifications

Brand Name :

kaixin

Model Number :

LM-S6

Certification :

UL CE ROHS ISO ETL SGS SAA Fcc EMC

Place of Origin :

China

MOQ :

1 Square Meter

Price :

Negotiation

Payment Terms :

Western Union, MoneyGram, T/T VISA

Supply Ability :

5,000 square meters per month

Packaging Details :

Packaging Details : Wooden box or Flight case Screen Dimension : 4x3m/6x4m/5x3m Controller System : Nova/Linsn Cabinet Size : 500x500mmx5mm Tube Chip Color : Full Color SMD3528/SMD3535 Thickness of Cabinet : 5mm(thinese place) LED Video Processor : LVP 605

Description

Programmable P6 LED Display Project , SMD 3535 RGB Advertising LED Wall Rental

Advantages of Raw materials :

1.Power Supply
Taiwan Meanwell brand Electric container,Or G-Energy power supply,more stable power output function, longer life, with protection mechanism against short circuit, overload,over temperature and over voltage.

2.LEDs
CREE / NICHIA / Epistar chips, with size of 12mil, 13mil,some are Cree as customized.better quality and working hour be guaranteed with using the medium level or more good chips.Better ensure the lamps cooling and effect of display with large chips package.

3.Cabinet
Good cabinet uniformity, adopt the standard cabinet dimension design,also can be designed accordIng to customers request,easy for installation and maintenance.

4.Wire and Cable
Famous brand China government standard Wire,the China government standard wire copper, high in quality and antioxidant capacity and ability of against conduct electricity.

5.Fan
ADDA brand fan, high wind capacity, durable life, 2 years of continuous working life. Low noise, low power consumption, durable life, high winds capacity, with certificate of UL / CUL, TUV,and CE certificate.

Technical Specification:

Pixel Pitch	6.25mm
Dots per Cabinet	80x80
Pixel Density	25,600 dots/m2
Best Viewing Distance	8 m
Scan mode	1/5 scan
Cabinet Weight	7.5 kg
Power Concumption	Max.400W/m2
Brigtness	5500 nits
Cabinet Size	W500mm x L1,000mm
Pixel Type and Configuration	SMD3535 (white)
Cabinet Material	Aluminum
Viewing Angle	120°(Horizontal)/55°±5o(Vertical)
Protection Level	IP65/outdoor
Refresh Rate	2880Hz
Color Temperature	6500-9500K (can be customize)
Operating Temperature Range	-20 to 45
Working Voltage	AC90~264V, 47~63Hz
Lifetime(50% brightness)	>80,000 hours
Certification	CE, RoHS, FCC
Connector	Neutrik/ Weipu

1. Seamless --- precision die casting aluminum panel, light weight and more durable.
2. Quality SMD LEDs --- with wide viewing angle to ensure vivid and sharp images and video.
3. Energy saving --- 42V power supply, lower power consumption and protect environment.
4. High refresh rate and high gray scale --- ensures the LED display to take on more perfect images.
5. Noiseless --- silence with no fan design.
6. Easy and fast installation --- no tool assembly and disassembly with patented quick lock for
seamless assembly and performance.

Application: Widely used for product launch, trade show, exhibition, shopping mall, conference, church, drama,
amusement park, advertising, rental, variety of some high resolution requested applications.
