P16 Football Stadium LED Screens White SMD3535 for Advertising Anti - UV

Specifications

Brand Name :

kaixin

Model Number :

LM-P10 DIP RGB

Certification :

UL CE ROHS ISO ETL SGS SAA Fcc EMC

Place of Origin :

China

MOQ :

1 Square Meter

Price :

Negotiation

Payment Terms :

Western Union, MoneyGram, T/T VISA

Supply Ability :

5,000 square meters per month

Packaging Details :

Packaging Details : Wooden box or Flight case Scan : 1/4Scan,Constant Current Refresh Rate : 1080 HZ LED type : SMD3535 Viewing distance : 10-100 meters Power Supply : Meanwell G-enery Brightness : >7400 cd/m2 Power Consumption (Max) : 700W/sq.m Weight of

Description

P16 Football Stadium LED Screens White SMD3535 for Advertising Anti - UV

Function and Technology Character Introduction:

1, High brightness, at most 8,000nits, can be used directly under the sunshine.

2, Ingress protection being IP65, weather proof and dust proof.

3, High brightness uniformity and color uniformity(≥95%)

4, Excellent heat dissipation.

5, Good anti-UV and anti-oxidation performance.

6, Large viewing distance, 120° in horizontal, 60° in vertical

SPECIFICATIONS Parameters:

Pixel Pitch	PH6mm	PH8mm	PH10mm
LED Encapsulation	White SMD 3535	White SMD 3535	White SMD 3535
Module Resolution(W*H)	32*32	32*16	32*16
Pixel Density	27777 Pixel/ sqm	15625 Pixel/sqm	10000 Pixel/sqm
Driving Method	1/4 Scan	1/4 Scan	1/2 Scan
Refresh Frequency	≥1920Hz (Support High refresh rate, depand on the system configuration)
Driver IC	Special constant current IC with height refresh rate & height grey scale
Grey Scale	14Bit(depending on zhe system and IC configuration)
Module Size	192*192	256*128	320*160
White balance Brightness	7000cd/sqm	6500cd/ sqm	5500cd/sqm
Color Temperature	8000K±500 (adjustable)
Viewing Angle	Horizontal 130°Vetical 100°
Optimal Viewing Distance	>6m	>8m	>10m
Working Voltage	DC4.2V
Max Power Consumption	30W/PCS	30W/PCS	30W/PCS
Avg. Power Consumption	15W/PCS	15W/PCS	15W/PCS
Lifetime	50000hours
Operating Temperature	–10℃~ 65℃
Net weight	0.50Kg/pcs	0.57Kg/pcs	1Kg/pcs

1. High uniformity for LED
2. High performance of anti-vibration
3. Easy assembly
4. Extreme low blind LED rate.
5. CE UL FCC certified

P10 Led Module features:
New structure design, meet the Hanging&wall mounted assembly requirements, and meet indoor & outdoor requirements
With ultra high refresh rate, to ensure clear picture
Fast and convenient assembly and dismount system
High brightness Contrast:4000:1, which is a very high level to ensure a vivid image of our LED display screen system
Long-term Brightness:More 6500-nit brightness(for outdoor full color led display)(2000 nits brightness for indoor full color led display)capacity throughout product lifetime of the LED display screen.
Easy Installation & Using: easy & simple installation interface and user friendly software to ensure the user friendly interface of the LED display screen system
Convenient Servicing: Front and rear cabinet access make the maintance work very convenient and low cost to help you concentrate more time and energy on your main marketing promotion business.
Range of Application: Large meeting place, stadium, bank, post & telecommunication bureau, governmental organizations, terminal, wharf, station, securities market and other transaction markets, medical system, electrical power system, exhibition building and other many places on promotion, advertisement, information release and guidance.
