P8 RGB Programmable LED Message Board , 3G / WIFI Wireless Control Custom LED Sign
Product Description:
These are very easy to program with software we provide. Data can be transferred through USB or LAN . It constantly displays Full colorLogos , Videos, Text , Neon sign features, Images , time , Animations, stopwatch ,countdown with hundred of special effects. You can add any image or logo of your choice.
Our 1/4 duty module provides a sign that is up-to 30% brighter than 1/8 duty sign that you see from other suppliers.
1. Use LAN option and no need to go outside. Sit in your office and control sign up to 100 meter away.
2. Schedule the messages , just set the time at which you want to display the message and feel free. No need to update same events again and again.
3. Auto On / Off option .
4. Heavy duty brackets & screws
5. User manual , video tutorial and online technical support.
6. Fully accessible rare panel for easy repairs
LED moving sign introduction
Multi language: English/Spanish/Russia/Inter.char.set…..
Display one line/two lines/three lines/four lines English char.
Technology Specifications:
Item | P8 outdoor full color led sign display |
LED chip | Epistar/Silan |
Physical Pixel Pitch | 8mm |
Physical Pixel Density | 15,625dots/m2 |
Pixel composition | 1Red, 1Green,1Blue |
Moduel Size | 256*128mm, 320mmx160mm |
Moduel resolution | 40*20dots |
Cabinet thickness | < 170 mm |
Bracket of cabinet | Easy to install onto the LED cabinet and uninstall . |
Brightness | ≥ 7000nits |
Colors | 16.7million |
Viewing angle | Horizontal ≥120°, Vertical : ≥ 90° |
Viewing distance | 6m-300m |
Soft Rubber Mask | To protect player and LED display itself . |
Scan frequency | ≥1200 Hz |
There will be one receive card in each cabinet | |
sparked .Also it is very easy to move and connetct | |
Video Frame Rate | ≥150 fps |
Color temperature | 6500°K to 9500°K adjustable |
Control method | Controlled by PC, synchronous display |
Life span( half brightness) | ≥100,000 hours |
Weight | 30-60Kg /sqm |
IP rate | IP65 ( front side and rear side) |
Average power consumption | 300W/sqm |
P8 digital led sign display function introduction:
1) High intensity and can be adjusted, so can meet the request of the customers according the application environment.
2) Best equality, commendably solve the problem of the mosaic, have the excellent consistency of light.
3) Big viewing angle to 120 degree at horizontal line, 90 degree at vertical line, you can see at every angle at this range, high brightness, high resolution, clear and non-flash screen image, long service life.
Products Advantages:
1) Price: we have the best competitive price at the market, also have the same even better quality.
2) Quality: From material to finished product, from design to produce, we control all steps, that's the guarantee of the quality and reliability.
3) Service: 5 years warranty.
