LWL-120 Custom Crawler Mucking Loader 120 m3/h Loading capacity
LWL-120 Custom Crawler Mucking Loader 120 m3/h Loading capacity
LWL-120 Custom Crawler Mucking Loader 120 m3/h Loading capacity
LWL-120 Custom Crawler Mucking Loader 120 m3/h Loading capacity
Specifications
Brand Name :
kamach
Model Number :
LWL-120
Certification :
CE,EAC
Place of Origin :
China
MOQ :
1 Unit
Payment Terms :
T/T 30% advance payment
Supply Ability :
1 Unit 8 months
Delivery Time :
8-10 months
Loading capacity :
120 m³/h
Machine weight :
13600 kgs
Min. turning radius :
≥7 m
Excavating width :
≥5900 mm
Excavating depth :
≥800 mm
Excavating height :
≥3350 mm
Excavating distance :
≥2300 mm
Loading width :
≥5900 mm
Discharge height :
1750-2000 mm
Unloading distance :
≥3000 mm
Grade ability :
30 deg
Max. slope :
≤26 deg
Conveyor speed :
33±2 m/min
Description

KAMACH offer a wide range of underground mucking loaders. we have a wide range of size options to suit your excavation needs in underground mining and tunneling applications.. We also offer custom design services to meet your specific requirements.

ZWY-120 is a mucking loader that can excavate and transport rocks in tunnel sections above 3.5×3.5, with rock size up to 600 mm. It has a dig arm that shovels rocks into the conveyor trough.

It’s a versatile, efficient and durable mucking loader that can handle any terrain and excavation. It will help you achieve a high productivity and low operational cost.
