C 4038 K30V CARB Toroidal Roller Bearings, Cylindrical Bore,Tapered Bore
C 4038 K30V CARB Toroidal Roller Bearings, Cylindrical Bore,Tapered Bore
C 4038 K30V CARB Toroidal Roller Bearings, Cylindrical Bore,Tapered Bore
C 4038 K30V CARB Toroidal Roller Bearings, Cylindrical Bore,Tapered Bore
C 4038 K30V CARB Toroidal Roller Bearings, Cylindrical Bore,Tapered Bore
C 4038 K30V CARB Toroidal Roller Bearings, Cylindrical Bore,Tapered Bore
C 4038 K30V CARB Toroidal Roller Bearings, Cylindrical Bore,Tapered Bore
C 4038 K30V CARB Toroidal Roller Bearings, Cylindrical Bore,Tapered Bore
Specifications
Model Number :
C 4038 K30V
MOQ :
1PCS
Price :
FOB
Packaging Details :
Carton Box
Delivery Time :
within one day
Payment Terms :
T/T In advance
Supply Ability :
5000PCS
Description

Specifications

CARB toroidal roller bearings

CARB toroidal roller bearing
CARB toroidal roller bearings combine the self-aligning capability of spherical roller bearings with the axial displacement ability of cylindrical roller bearings. CARB bearings can also have the compact cross section and high load carrying capacity normally associated with needle roller bearings.
CARB bearings are intended exclusively as non-locating bearings. They can simplify the bearing arrangement design for shafts that are subjected to thermal expansion/contraction because axial displacement is accommodated within the bearing, virtually without friction. Bearing systems consisting of a spherical roller bearing in the locating position and a CARB bearing in the non-locating positionprovide a space and weight-saving bearing system with a low cost of ownership. CARB bearings can reduce noise and vibration levels, e.g. in paper machines and fans. CARB bearings are single row bearings with long, slightly barrel-shaped symmetrical rollers.
The outer ring has a torus-shaped raceway with a profile radius extending beyond the centre of the bearing. The inner ring raceway is shaped accordingly. The rollers of CARB bearings are self-guiding, i.e. they always adopt the position where the load is favourably distributed over the roller length, irrespective of whether the bearing rings are misaligned or axially displaced. The ability to distribute loads favourably keeps the friction and friction-generated heat at low level. Lower operating temperature extends the service life of the lubricant and the bearing.

Factors that influence CARB bearing performance

Bearing performance is not only determined by load or speed ratings. There are a number of other factors that contribute to bearing performance. To a large extent, performance is influenced by the geometry of the rollers, raceways and cages, the heat treatment, as well as the surface finish of all contact surfaces.
Main factors, which influence CARB bearing performance include, but are not limited to:

Some stock list shown as follows :


C 2224

C 3030 KV

C 4034 K30V

C 3138

C 2224 K

C 3030 MB

C 4034 V

C 3138 K

C 3224

C 3030 V

C 3134

C 4138 K30V

C 3224 K

C 4030 K30V

C 3134 K

C 4138 V

C 3026

C 4030 V

C 4134 K30V

C 2238

C 3026 K

C 3130

C 4134 V

C 2238 K

C 4026

C 3130 K

C 2234

C 2238 K/HA3C4

C 4026 K30

C 4130 K30V

C 2234 K

C 3040

C 4026 K30V

C 4130 V

C 3036

C 3040 K

C 4026 V

C 2230

C 3036 K

C 3040 K/HA3C4

C 4126 K30V/VE240

C 2230 K

C 3036 K/HA3C4

C 4040 K30V

C 4126 V/VE240

C 3032

C 4036 K30V

C 4040 V

C 2226

C 3032 K

C 4036 V

C 3140

C 2226 K

C 4032

C 3136

C 3140 K

C 2326 K/VE240

C 4032 K30

C 3136 K

C 3140 K/HA3C4

C 2326/VE240

C 4032 K30V

C 3136 K/HA3C4

C 4140 K30V

C 3028

C 4032 V

C 4136 K30V

C 4140 V

C 3028 K

C 3132 KMB

C 4136 V

C 3044

C 4028 K30V

C 3132 MB

C 3236

C 3044 K

C 4028 V

C 4132 K30V

C 3236 K

C 3044 K/HA3C4

C 4128 K30V

C 4132 V

C 3038

C 4044 K30V

C 4128 V

C 3232

C 3038 K

C 4044 V

C 2228

C 3232 K

C 3038 K/HA3C4

C 3144

C 2228 K

C 3034

C 4038 K30V

C 3144 K

Brand: SKF - SKF

Rolling element type: drum-shaped roller

Bearing Type: CARB

Seal type: no seal

The totalbearings company can also provide the following bearings:

SKF Bearings: C6912V

FAG Bearings: No

NSK Bearings: No

NTN Bearing: No

TIMKEN bearings: No

KOYO bearings: No

Bearing dimensions: inner diameter of 60mm outside diameter of 85mm thickness of 45mm

Weight: 0.84kg

Load: basic rated dynamic load is 190KN basic rated static load 335KN

Reference Speed: grease 1900r/min

Other bearing models:

C 4134 K30V *

C 2209 V *

C 2215 *

C 4022 K30V *

C 4032 K30V *

C 4044 K30V *

C 4910 K30V *

C 2215 K *

C 4022 MB *

C 4032 V *

C 4044 V *

C 4910 V *

C 2215 KV *

C 4022 V *

C 3132 KMB *

C 3144 *

C 5910 V *

C 2215 V *

C 4122 K30V *

C 3132 MB *

C 3144 K *

C 6910 V *

C 2315 *

C 4122 V *

C 4132 K30V *

C 3144 K/HA3C4 *

C 4010 K30TN9 *

C 2315 K *

C 2222 *

C 4132 V *

C 2244 *

C 4010 K30V *

C 4916 K30V *

C 2222 K *

C 3232 *

C 2244 K *

C 4010 TN9 *

C 4916 V *

C 3024 *

C 3232 K *

C 2244 K/HA3C4 *

C 4010 V *

C 5916 V *

C 3024 K *

C 3034 *

C 3048 *

C 2210 KTN9 *

C 2216 *

C 3024 KV *

C 3034 K *

C 3048 K *

C 2210 KV *

C 2216 K *

C 3024 V *

C 4034 K30V *

C 3048 K/HA3C4 *

C 2210 TN9 *

C 2216 KV *

C 4024 K30V *

C 4034 V *

C 3148 *

C 2210 V *

C 2216 V *

C 4024 V *

C 3134 *

C 3148 K *

C 4911 K30V *

C 2316 *

C 4124 K30V *

C 3134 K *

C 3148 K/HA3C4 *

C 4911 V *

C 2316 K *

C 4124 V *

C 3052 *

C 5911 V *

C 4917 K30V *

C 2224 *

C 4134 V *

C 3052 K *

C 6911 V *

C 4917 V *

C 2224 K *

C 2234 *

C 3052 K/HA3C4 *

C 2211 KTN9 *
