High Resolution 1920x1080 21.5 Inch SAW Touch Monitor For Kiosks
High Resolution 1920x1080 21.5 Inch SAW Touch Monitor For Kiosks
High Resolution 1920x1080 21.5 Inch SAW Touch Monitor For Kiosks
High Resolution 1920x1080 21.5 Inch SAW Touch Monitor For Kiosks
High Resolution 1920x1080 21.5 Inch SAW Touch Monitor For Kiosks
High Resolution 1920x1080 21.5 Inch SAW Touch Monitor For Kiosks
Specifications
Brand Name :
KeeTouch
Model Number :
KOT-215P-006(KOT-0215US-SA6BP)
Certification :
CCC, UL, FCC, CE, CB, RoHS
Place of Origin :
Shenzhen，China
MOQ :
1 piece
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
1000 Pieces per Week
Delivery Time :
7-15 work days
Packaging Details :
carton box
Series :
OT
Display Active Area :
476.6*268(mm)
Suggested Resolution :
1920*1080 @ 60Hz
Support Colors :
16.7M
Response Time :
≤8ms(USB) ; ≤12ms(RS232)
Pure LCD Panel :
10%～90%
Product name :
SAW Touch monitor
Description

21.5 Inch SAW Touch Monitor High Resolution 1920*1080 For Kiosks

SAW Touch Monitor Main Features:

  • KeeTouch SAW touch technology, fast response with great touch experience
  • High quality SAW touch monitor with high resolution, high contrast and wide viewing angle
  • Dust-proof SAW touch monitor, easy for maintenance
  • Multiple mounting options include VESA mount, horizontal vertical brackets mount
  • VGA and DVI interfaces,USB+RS232 for touch input
  • Support systems: XP,WIN7,WIN8,WIN10, Linux, Android
  • Other sizes are optional or customized (7’’- 43’’)

SAW Touch Monitor Specifications

Complete Machine
Model No. KOT-0215US-SA6BP (P/N:KOT-215P-006)
Series OT
Display Type 16:9 Ratio 21.5" TFT-LCD
Active Area 476.6*268(mm)
Monitor Dimensions (W*H*D) 515*313*52(mm)
Suggested Resolution 1920*1080 @ 60Hz
Support Colors 16.7M
Brightness (Typ.) Pure LCD Panel 250cd/m2
With Touch Monitor 225cd/m2
Response Time (Typ.) 5ms
Viewing Angle(Typ.at CR＞10)) Horizontal(left/right) 85°/85°
Vertical(up/down) 80°/80°
Contrast Ratio (Typ.) 1000:1
Video Input VGA/DVI
Frequency (H/V) 30～80KHz / 50～76Hz
Power Supply

Type: External brick

Display voltage: DC 12V±5%

Input (line) voltage: 100-240 VAC, 50-60 Hz
Environment Operating Temp. 0～50°C
Operating RH 20%～80%
Storage Temp. -20～60°C
Storage RH 10%～90%
MTBF ≥30,000 Hours
LED Back Light Life (Typ.) ≥30,000 Hours
Weight(N.W/G.W) 7Kg(1pcs)/17Kg(2pcs in one package)
Package dimensions 605*400*195(mm)(2pcs in one package)
Power Consumption Standby Power: ≤1.5W / Operating Power: ≤30W
Mount Interface

1.VESA 75mm and 100mm

2.Mount bracket, horizontal or vertical mount
OSD Control Buttons AUTO,+,POWER,-,MENU
Function Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset
Agency approvals CCC, ETL, FCC, CE, CB, RoHS
Regular Warranty 1 year

Touch Screen
Touch Type 21.5" Surface acoustic wave touch screen
Touch input USB/RS232
Response Time ≤8ms(USB) ; ≤12ms(RS232)
Hardness 7H
Light Transmittance ≥90%
Support System XP,WIN7,WIN8,WIN10,Linux,Android
Active Area 477*268(mm)
Thickness 6±0.2(mm)
Touch Test ≥50,000,000 times
Input Voltage DC 5V±5%

SAW Touch Monitor Mechanical Dimensions

High Resolution 1920x1080 21.5 Inch SAW Touch Monitor For Kiosks

Applications

Widely used in industries such as retail, gaming, kiosk, self-service, finance, transit, conference, education, healthcare, public service, e-commerce, hotels, restaurants, travel service, payment systems, museums, exhibitions, smart home, subways, railway stations, control and operation systems, airports, entertainments, etc.

High Resolution 1920x1080 21.5 Inch SAW Touch Monitor For Kiosks

FAQ

1. Are you a manufacturer?

Yes, KeeTouch is a professional touch product manufacturer for over 16 years, located in Shenzhen, China.

2. What’s your MOQ for SAW touch monitor?

Our minimum order quantity is 1pc only.

3. What is your warranty period for SAW touch monitor?

Our regular warranty is 12 months for all the products, with 2-3 years Warranty (optional).

4. Can you produce the product according to the customer's requirements?

Sure, with 40+ Professional R & D engineers, OEM and ODM are offered.

5. What is your delivery time?

3-5 work days for inventory orders, 7-15 business days for bulk production.
