21.5 Inch SAW Touch Monitor With 1000:1 High Contrast Ratio
21.5 Inch SAW Touch Monitor With 1000:1 High Contrast Ratio
21.5 Inch SAW Touch Monitor With 1000:1 High Contrast Ratio
21.5 Inch SAW Touch Monitor With 1000:1 High Contrast Ratio
21.5 Inch SAW Touch Monitor With 1000:1 High Contrast Ratio
21.5 Inch SAW Touch Monitor With 1000:1 High Contrast Ratio
21.5 Inch SAW Touch Monitor With 1000:1 High Contrast Ratio
21.5 Inch SAW Touch Monitor With 1000:1 High Contrast Ratio
Specifications
Brand Name :
KeeTouch
Model Number :
KOT-215P-006(KOT-0215US-SA6BP)
Certification :
CCC, UL, FCC, CE, CB, RoHS
Place of Origin :
Shenzhen，China
MOQ :
1 piece
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
1000 Pieces per Week
Delivery Time :
7-15 work days
Packaging Details :
carton box
Series :
OT
Response Time :
≤8ms(USB) ; ≤12ms(RS232)
Light Transmittance :
≥90%
Operating Temp. :
0～50°C
Operating RH :
20%～80%
Storage Temp. :
-20～60°C
Storage RH :
10%～90%
Hardness :
7H
Description

21.5 Inch SAW Touch Monitor With 1000:1 High Contrast Ratio

SAW Touch Monitor Main Features:

KeeTouch SAW touch monitor delivers high resolution, high light transmission with superior image clarity. The stable, drift-free operation of Surface Acoustic Wave touchscreen technology provides an accurate touch response. And it can be activated by using a finger, gloved hand, or passive stylus. It's well compatible with XP, WIN7, WIN8, WIN10, Linux, Android. Other sizes can be offered (7" to 43").

SAW Touch Monitor Specifications

Complete Machine
Model No. KOT-0215US-SA6BP (P/N:KOT-215P-006)
Series OT
Display Type 16:9 Ratio 21.5" TFT-LCD
Active Area 476.6*268(mm)
Monitor Dimensions (W*H*D) 515*313*52(mm)
Suggested Resolution 1920*1080 @ 60Hz
Support Colors 16.7M
Brightness (Typ.) Pure LCD Panel 250cd/m2
With Touch Monitor 225cd/m2
Response Time (Typ.) 5ms
Viewing Angle(Typ.at CR＞10)) Horizontal(left/right) 85°/85°
Vertical(up/down) 80°/80°
Contrast Ratio (Typ.) 1000:1
Video Input VGA/DVI
Frequency (H/V) 30～80KHz / 50～76Hz
Power Supply

Type: External brick

Display voltage: DC 12V±5%

Input (line) voltage: 100-240 VAC, 50-60 Hz
Environment Operating Temp. 0～50°C
Operating RH 20%～80%
Storage Temp. -20～60°C
Storage RH 10%～90%
MTBF ≥30,000 Hours
LED Back Light Life (Typ.) ≥30,000 Hours
Weight(N.W/G.W) 7Kg(1pcs)/17Kg(2pcs in one package)
Package dimensions 605*400*195(mm)(2pcs in one package)
Power Consumption Standby Power: ≤1.5W / Operating Power: ≤30W
Mount Interface

1.VESA 75mm and 100mm

2.Mount bracket, horizontal or vertical mount
OSD Control Buttons AUTO,+,POWER,-,MENU
Function Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset
Agency approvals CCC, ETL, FCC, CE, CB, RoHS
Regular Warranty 1 year

Touch Screen
Touch Type 21.5" Surface acoustic wave touch screen
Touch input USB/RS232
Response Time ≤8ms(USB) ; ≤12ms(RS232)
Hardness 7H
Light Transmittance ≥90%
Support System XP,WIN7,WIN8,WIN10,Linux,Android
Active Area 477*268(mm)
Thickness 6±0.2(mm)
Touch Test ≥50,000,000 times
Input Voltage DC 5V±5%

SAW Touch Monitor Mechanical Dimensions

21.5 Inch SAW Touch Monitor With 1000:1 High Contrast Ratio

Applications

Widely used in industries such as retail, gaming, kiosk, self-service, finance, transit, conference, education, healthcare, public service, e-commerce, hotels, restaurants, travel service, payment systems, museums, exhibitions, smart home, subways, railway stations, control and operation systems, airports, entertainments, etc.

21.5 Inch SAW Touch Monitor With 1000:1 High Contrast Ratio

FAQ

1. Are you a manufacturer?

Yes, KeeTouch is a professional touch product manufacturer for over 16 years, located in Shenzhen, China.

2. What is your warranty period for the SAW Touch Monitor?

Our regular warranty is 12 months for all the products, with 2-3 years Warranty (optional).

3. Can you produce the SAW Touch Monitor according to the customer's requirements?

Sure, with 40+ Professional R & D engineers, OEM and ODM are welcomed.

4. What package do you provide?

Our package usually is carton.

5. Do you have stock?

Yes, we have a large quantity of stock for our regular model products.

6. What are the shipping ways?

We will ship the goods according to customer’s requirement. For sample, normally by FedEx, DHL, UPS, TNT. For bulk order, by air or by sea.

7. Do you give any discount for the SAW Touch Monitor?

We will do utmost to support you with the competitive price, also good service will be offered.
