IP65 Waterproof 5:4 Ratio Touch Display Infrared Touch Monitor 17''
IP65 Waterproof 5:4 Ratio Touch Display Infrared Touch Monitor 17''
IP65 Waterproof 5:4 Ratio Touch Display Infrared Touch Monitor 17''
IP65 Waterproof 5:4 Ratio Touch Display Infrared Touch Monitor 17''
IP65 Waterproof 5:4 Ratio Touch Display Infrared Touch Monitor 17''
IP65 Waterproof 5:4 Ratio Touch Display Infrared Touch Monitor 17''
IP65 Waterproof 5:4 Ratio Touch Display Infrared Touch Monitor 17''
IP65 Waterproof 5:4 Ratio Touch Display Infrared Touch Monitor 17''
IP65 Waterproof 5:4 Ratio Touch Display Infrared Touch Monitor 17''
IP65 Waterproof 5:4 Ratio Touch Display Infrared Touch Monitor 17''
IP65 Waterproof 5:4 Ratio Touch Display Infrared Touch Monitor 17''
IP65 Waterproof 5:4 Ratio Touch Display Infrared Touch Monitor 17''
Specifications
Brand Name :
KeeTouch
Model Number :
KOT-0170U-IR3W(KOT-170P-021)
Certification :
CCC, UL, FCC, CE, CB, RoHS
Place of Origin :
Shenzhen，China
MOQ :
1 piece
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
10000 Piece/Pieces per Week
Delivery Time :
7-15 work days
Packaging Details :
two pieces per carton
Pure LCD panel brightness :
250cd/m2
Touch Monitor Brightness :
135cd/m2
Horizontal viewing angle (left/right) :
85°/85°
Vertical Viewing Angle (Left/Right) :
80°/80°
Active Area :
337.3*270.3(mm)
Regular Warranty :
1 year
Support Colors :
16.7M
Product name :
Infrared Touch Monitor
Description

17'' IR Touch Monitor IP65 Waterproof 5:4Ratio Touch Display

Infrared Touch Monitor Main Features

This 17 inch IR touch monitor comes with main specifications as following: IP65 waterproof, dust-proof and vandal-proof, 5:4 ratio display type, 1280*1024 resolution, 1000:1 high contrast ratio with wide viewing angle. This industrial grade industrial touch monitor delivers super image quality. It can support below system, XP, WIN7, WIN8, WIN10, Linux and Android.

Infrared Touch Monitor Specifications

Complete Machine
Model No. KOT-0170U-IR3W(KOT-170P-021)
Series OT
Display Type 5:4 Ratio 17" TFT-LCD,LED backlight
Active Area 337.3*270.3(mm)
Monitor Dimensions (W*H*D) 381*313*52(mm)
Suggested Resolution 1280*1024 @ 60Hz
Support Colors 16.7M
Response Time (Typ.) 5ms
Contrast Ratio (Typ.) 1000:1
Video Input VGA/DVI
Frequency (H/V) 30～80KHz / 60～75Hz
Power Supply Type: External brick
Display voltage: DC 12V±5%
Input (line) voltage: 100-240 VAC, 50-60 Hz
Environment Operating Temp. 0～50°C
Operating RH 20%～80%
Storage Temp. -20～60°C
Storage RH 10%～90%
Power Consumption Standby Power: ≤1.5W / Operating Power: ≤20W
Mount Interface 1.VESA 75mm and 100mm
2.Mount bracket, horizontal or vertical mount
OSD Control Buttons AUTO,+,POWER,-,MENU
Function Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset
Regular Warranty 1 year
Touch Screen
Touch Type 17" Infrared touch screen
Touch input USB
Response Time 20ms
Hardness 7H
Light Transmittance ≥90%
Support System XP,WIN7,WIN8,WIN10,Linux,Android
Active Area 339*271(mm)
Thickness 9±1(mm)
Touch Test ≥50,000,000 times
Input Voltage DC 5V±5%
Infrared Touch Monitor Mechanical Dimensions

IP65 Waterproof 5:4 Ratio Touch Display Infrared Touch Monitor 17''

Best ir touch frame Applications

  • Retail
  • Gaming
  • Kiosk
  • self-service
  • Finance
  • Transit
  • Conference
  • Education
  • Healthcare
  • public service
  • e-commerce
  • Hotels
  • restaurants

IP65 Waterproof 5:4 Ratio Touch Display Infrared Touch Monitor 17''

Advantages of IR Touch Monitor

1. High durability: 55 inch ir touch frame are designed to withstand heavy usage and can handle millions of touch inputs. They are resistant to scratches, dust, and water, making them ideal for use in high-traffic areas.

2. High accuracy: ir touch frame 43 inch offer a high level of accuracy when it comes to touch input detection. This makes them suitable for applications that require precise touch inputs, such as drawing and design software.

3. Multi-touch support: ir touch screen monitor can detect multiple touch inputs simultaneously, allowing for multi-touch gestures such as pinch-to-zoom and two-finger scrolling.

FAQ

1. Are you a manufacturer?

Yes, KeeTouch is a professional touch product manufacturer for over 16 years, located in Shenzhen, China.

2. What’s your MOQ for the IR Touch Monitor?

Our minimum order quantity is 1pc only.

3. What is your warranty period for the IR Touch Monitor?

Our regular warranty is 12 months for all the products, with 2-3 years Warranty (optional).
