Wall Mounted 18.5 Inch PCAP Touch Screen Monitors Vandal Proof Touch Screen
Wall Mounted 18.5 Inch PCAP Touch Screen Monitors Vandal Proof Touch Screen
Wall Mounted 18.5 Inch PCAP Touch Screen Monitors Vandal Proof Touch Screen
Wall Mounted 18.5 Inch PCAP Touch Screen Monitors Vandal Proof Touch Screen
Wall Mounted 18.5 Inch PCAP Touch Screen Monitors Vandal Proof Touch Screen
Wall Mounted 18.5 Inch PCAP Touch Screen Monitors Vandal Proof Touch Screen
Wall Mounted 18.5 Inch PCAP Touch Screen Monitors Vandal Proof Touch Screen
Wall Mounted 18.5 Inch PCAP Touch Screen Monitors Vandal Proof Touch Screen
Specifications
Brand Name :
KeeTouch
Model Number :
KOT-185P-001(KOT-0185U-CA4P)
Certification :
FCC, CE, CB, RoHS,UL,BIS
Place of Origin :
Shenzhen, China
MOQ :
1piece
Price :
Negotiable
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
10000 Pieces per Week
Delivery Time :
7-15 work days
Packaging Details :
Carton
Active Area :
409.8*230.4(mm)
Contrast Ratio (Typ.) :
1000:1
Video Input :
VGA\DVI
Support Colors :
16.7M
Response Time :
8s
Power Consumption :
Standby Power: ≤1.5W / Operating Power: ≤15W
Touch Type :
18.5" Riot capacitive touch screens
Product name :
PCAP Touch Monitor
Warranty :
1 year
Brightness :
400cd/m2
Description

Wall Mounted 18.5 Inch PCAP Touch Screen Monitors Vandal Proof Touch Screen

PCAP Touch Monitor Description:

This PCAP touch monitor is vandal proof and waterproof, using PCAP technology to deliver high sensitive, fast response and accurate touch. With pure flat design and sleek look, it offers the versatility mounting optional including VESA mount75*75mm, 100*100mm, and brackets mount.

PCAP Touch Monitor Specifications


Complete Machine
Model No. KOT-185P-001(P/N:KOT-0185U-CA4P)
Series OT
Display Type 16:9 Ratio 18.5" TFT-LCD
Active Area 409.8*230.4(mm)
Monitor Dimensions (W*H*D) 449.4*270*46(mm)
Suggested Resolution 1920*1080@ 60Hz
Support Colors 16.7M

Brightness (Typ.)

 Pure LCD Panel 250cd/m2
With Touch Monitor 212cd/m2
Response Time (Typ.) 5ms
Viewing Angle(Typ.at CR＞10)) Horizontal(left/right) 85°/85°
Vertical(up/down) 80°/80°
Contrast Ratio (Typ.) 1000:1
Video Input VGA/DVI
Frequency (H/V) 37.8～68.4KHz / 50～76Hz

Power Supply

Type: External brick

Display voltage: DC 12V±5%

Input (line) voltage: 100-240 VAC, 50-60 Hz

Environment

 Operating Temp. 0～50°C
Operating RH 20%～80%
Storage Temp. -20～60°C
Storage RH 10%～90%
MTBF ≥30,000 Hours
LED Back Light Life (Typ.) ≥30,000 Hours
Weight(N.W/G.W) 3.64Kg(1pcs)/8.93Kg(2pcs in one package)
Package dimensions 525*190*385(mm)(2pcs in one package)
Power Consumption Standby Power: ≤1.5W / Operating Power: ≤25W

Mount Interface

1. VESA 75mm and 100mm

2. Mount bracket, horizontal or vertical mount

OSD Control

 Buttons AUTO,+,POWER,-,MENU
Function Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset
Agency approvals CCC, ETL, FCC, CE, CB, RoHS
Regular Warranty 1 year

Touch Screen
Touch Type 18.5" Riot capacitive touch screens
Touch input USB
Response Time ≤10ms
Hardness 6H
Light Transmittance ≥85%
Support System XP,WIN7,WIN8,WIN10,Linux,Android
Active Area 410.8*231.4(mm)
Thickness 4.3±0.2(mm)
Touch Test ≥50,000,000 times
Input Voltage DC 5V±5%

PCAP Touch Monitor Mechanical Dimensions

Wall Mounted 18.5 Inch PCAP Touch Screen Monitors Vandal Proof Touch Screen

Our Advantages

  • With over 16 years' experience, Keetouch is a leading manufacturer of touch products and supplier of touch solution.

  • Comprehensive product lines including PCAP/SAW/IR touch screen, Open frame touch monitors, all-in-one touch panel PCs, sheet metal cases.

  • Monthly capacity is more than 30,000 pcs
  • Based your needs, product design, logo and function including anti-glare, privacy film, brightness, hardware and software can be customized.

Applications

KeeTouch PCAP touch monitors are widely used in industries such as retail, gaming, kiosk, self-service, finance, transit, conference, education, healthcare, public service, e-commerce, hotels, restaurants, travel service, payment systems, museums, exhibitions, smart home, subways, railway stations, control and operation systems, airports, entertainments, etc.

Wall Mounted 18.5 Inch PCAP Touch Screen Monitors Vandal Proof Touch Screen

FAQ

1. What’s your MOQ for the PCAP touch monitor?

Our minimum order quantity is 1pc only.

2. What is your warranty period for the PCAP touch monitor?

Our regular warranty is 12 months for all the products, with 2-3 years Warranty (optional).

3. Are you a manufacturer?

Yes, KeeTouch is a professional touch product manufacturer for over 16 years, located in Shenzhen, China.

4. What is your delivery time?

3-5 work days for inventory orders, 7-15 business days for bulk production.

5. Do you give any discount?

We will do utmost to support you with the competitive price, also good service will be offered.
