15.6 Inch SAW Touch Monitor 1920x1080 Resolution Interactive Panel
15.6 Inch SAW Touch Monitor 1920x1080 Resolution Interactive Panel
15.6 Inch SAW Touch Monitor 1920x1080 Resolution Interactive Panel
15.6 Inch SAW Touch Monitor 1920x1080 Resolution Interactive Panel
15.6 Inch SAW Touch Monitor 1920x1080 Resolution Interactive Panel
15.6 Inch SAW Touch Monitor 1920x1080 Resolution Interactive Panel
15.6 Inch SAW Touch Monitor 1920x1080 Resolution Interactive Panel
15.6 Inch SAW Touch Monitor 1920x1080 Resolution Interactive Panel
Specifications
Brand Name :
KeeTouch
Model Number :
KOT-156P-004
Certification :
CCC, UL, FCC, CE, CB, RoHS
Place of Origin :
Shenzhen，China
MOQ :
1 piece
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
1000 Pieces per Week
Delivery Time :
7-15 work days
Packaging Details :
carton box
Display Type :
16:9 Ratio 15.6" TFT-LCD
Suggested Resolution :
1920*1080 @ 60Hz
Touch Type :
15" Surface acoustic wave touch screen
Monitor Dimensions (W*H*D) :
388.5*237.5*43(mm)
Contrast Ratio :
650:1
Video Input :
VGA、DVI
Regular Warranty :
1 year
LED Back Light Life (Typ.) :
30,000 Hours
Product name :
SAW Touch monitor
Description

15.6 Inch SAW Touch Monitor 1920x1080 Resolution Interactive Panel

SAW Touch Monitor Description:

KeeTouch SAW touch monitor integrates with SAW touch panel to enjoy a accurate touch and great interactive experience. The high resolution LCD screen delivers a great image quality. There are multiple interfaces like VGA, HDMI, USB, etc. It's compatible with XP, WIN7, WIN8, WIN10, Linux, Android. Multiple mounting options include horizontal bracket-mount and vertical bracket. Other sizes can be offered from 7" to 55".

SAW Touch Monitor Specifications

Complete Machine
Model No. KOT-0156U-SA4BP (P/N:KOT-156P-004)
Series OT
Display Type 16:9 Ratio 15.6" TFT-LCD
Active Area 344.23*193.54(mm)
Monitor Dimensions (W*H*D) 388.5*237.5*43(mm)
Suggested Resolution 1920*1080 @ 60Hz
Support Colors 16.7M
Brightness (Typ.) Pure LCD Panel 400cd/m2
With Touch Monitor 340cd/m2
Response Time (Typ.) 5ms
Viewing Angle(Typ.at CR＞10)) Horizontal(left/right) 70°/70°
Vertical(up/down) 60°/60°
Contrast Ratio (Typ.) 650:1
Video Input VGA/HDMI
Frequency (H/V) 30～80KHz / 50～76Hz
Power Supply

Type: External brick

Display voltage: DC 12V±5%

Input (line) voltage: 100-240 VAC, 50-60 Hz
Environment Operating Temp. 0～50°C
Operating RH 20%～80%
Storage Temp. -20～60°C
Storage RH 10%～90%
MTBF ≥15,000 Hours
LED Back Light Life (Typ.) ≥15,000 Hours
Weight(N.W/G.W) 3Kg(1pcs)/8.25Kg(2pcs in one package)
Package dimensions 468*150*323(mm)(2pcs in one package)
Power Consumption Standby Power: ≤1.5W / Operating Power: ≤15W
Mount Interface

1.VESA 75mm and 100mm

2.Mount bracket, horizontal or vertical mount
OSD Control Buttons AUTO,+,POWER,-,MENU
Function Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset
Agency approvals CCC, ETL, FCC, CE, CB, RoHS
Regular Warranty 1 year

Touch Screen
Touch Type 15" Surface acoustic wave touch screen
Touch input USB
Response Time ≤10ms
Hardness 7H
Light Transmittance ≥90%
Support System XP,WIN7,WIN8,WIN10,Linux,Android
Active Area 346*195(mm)
Thickness 4±0.2(mm)
Touch Test ≥50,000,000 times
Input Voltage DC 5V±5%

SAW Touch Monitor Mechanical Dimensions

15.6 Inch SAW Touch Monitor 1920x1080 Resolution Interactive Panel

Applications

KeeTouch products are widely used in industries such as retail, gaming, kiosk, self-service, finance, transit, conference, education, healthcare, public service, e-commerce, hotels, restaurants, travel service, payment systems, museums, exhibitions, smart home, subways, railway stations, control and operation systems, airports, entertainments, etc.

15.6 Inch SAW Touch Monitor 1920x1080 Resolution Interactive Panel

Our Advantages:

  • Completely and strictly quality control system
  • High-tech and innovative enterprise
  • Efficient Warehousing and Logistics
  • 30,000+ manufacturing capacity per year
  • More than 15 years professional experience in touch product industry

FAQ

1. Are you a manufacturer?

Yes, KeeTouch is a professional touch product manufacturer for over 16 years, located in Shenzhen, China.

2. What’s your MOQ for the SAW touch monitor?

Our minimum order quantity is 1pc only.

3. What is your warranty period for the SAW touch monitor?

Our regular warranty is 12 months for all the products, with 2-3 years Warranty (optional).

4. Can you produce the SAW touch monitor according to the customer's requirements?

Sure, with 40+ Professional R & D engineers, OEM and ODM are welcomed.

5. Do you have the SAW touch monitor in stock?
Yes, we have a large quantity of stock for our regular model products.

6. Do you give any discount?
We will do utmost to support you with the competitive price, also good service will be offered.
