Industrial Open Frame SAW Touch Monitor Touchscreen 19 Inch Surface Waterproof
Industrial Open Frame SAW Touch Monitor Touchscreen 19 Inch Surface Waterproof
Industrial Open Frame SAW Touch Monitor Touchscreen 19 Inch Surface Waterproof
Industrial Open Frame SAW Touch Monitor Touchscreen 19 Inch Surface Waterproof
Industrial Open Frame SAW Touch Monitor Touchscreen 19 Inch Surface Waterproof
Industrial Open Frame SAW Touch Monitor Touchscreen 19 Inch Surface Waterproof
Industrial Open Frame SAW Touch Monitor Touchscreen 19 Inch Surface Waterproof
Industrial Open Frame SAW Touch Monitor Touchscreen 19 Inch Surface Waterproof
Industrial Open Frame SAW Touch Monitor Touchscreen 19 Inch Surface Waterproof
Industrial Open Frame SAW Touch Monitor Touchscreen 19 Inch Surface Waterproof
Specifications
Brand Name :
KeeTouch
Model Number :
KOT-0190US-SA4BCW
Certification :
CCC, ETL, FCC, CE, CB, RoHS
Place of Origin :
Shenzhen，China
MOQ :
1 piece
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
1000 Pieces per Week
Delivery Time :
7-15 work days
Packaging Details :
carton box
Display Type :
5:4 Ratio 19" TFT-LCD
Suggested Resolution :
1280x1024 @ 60Hz
Contrast Ratio :
1000:1
Video Input :
VGA/DVI
Regular Warranty :
1 year
Support System :
XP,WIN7,WIN8,WIN10,Linux,Android
Response Time :
≤8ms(USB) ; ≤12ms(RS232)
Product name :
SAW Touch monitor
Description

19 Inch SAW Touch Monitor Waterproof Industrial Grade Open Frame

SAW Touch Monitor Main Features

  • KeeTouch SAW touch screen, finger operation
  • Professional design with front surface waterproofing function
  • The SAW Touch Monitor has high contrast ratio and wide viewing angle
  • Multiple mounting options include VESA mount, horizontal vertical brackets mount
  • VGA+DVI interfaces,USB/ RS232 for touch
  • the SAW Touch Monitor support Operation system: XP,WIN7,WIN8,WIN10, Linux, Android
  • Other sizes are optional (7’’- 43’’)

SAW Touch Monitor Specifications

Complete Machine
Model No. KOT-0190US-SA4BCW (P/N:KOT-190C-013)
Series OT
Display Type 5:4 Ratio 19" TFT-LCD
Active Area 376.32*301.06 (mm)
Monitor Dimensions (W*H*D) 416*344*54(mm)
Suggested Resolution 1280x1024 @ 60Hz
Support Colors 16.7M
Brightness (Typ.) Pure LCD Panel 250cd/m2
With Touch Monitor 225cd/m2
Response Time (Typ.) 5ms
Viewing Angle(Typ.at CR＞10)) Horizontal(left/right) 85°/85°
Vertical(up/down) 80°/80°
Contrast Ratio (Typ.) 1000:1
Video Input VGA/DVI
Frequency (H/V) 37.9 -80KHz/ 60～75Hz
Power Supply

Type: External brick

Display voltage: DC 12V±5%

Input (line) voltage: 100-240 VAC, 50-60 Hz
Environment Operating Temp. 0～50°C
Operating RH 20%～80%
Storage Temp. -20～60°C
Storage RH 10%～90%
MTBF ≥50,000 Hours
LED Back Light Life (Typ.) ≥50,000 Hours
Weight(N.W/G.W) 5Kg(1pcs)/13.5Kg(2pcs in one package)
Package dimensions 530*250*460(mm)(2pcs in one package)
Power Consumption Standby Power: ≤1.5W / Operating Power: ≤20W
Mount Interface

1.VESA 75mm and 100mm

2.Mount bracket, horizontal or vertical mount
OSD Control Buttons AUTO,+,POWER,-,MENU
Function Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset
Agency approvals CCC, UL, FCC, CE, CB, RoHS
Regular Warranty 1 year
Touch Screen
Touch Type 19" Surface acoustic wave touch screen
Touch input USB/RS232
Response Time ≤8ms(USB) ; ≤12ms(RS232)
Hardness 7H
Light Transmittance ≥90%
Support System XP,WIN7,WIN8,WIN10,Linux,Android
Active Area 382*305(mm)
Thickness 4±0.1(mm)
Touch Test ≥50,000,000 times
Input Voltage DC 5V±5%

SAW Touch Monitor Mechanical Dimensions

Industrial Open Frame SAW Touch Monitor Touchscreen 19 Inch Surface Waterproof

Applications

Widely used in industries such as retail, gaming, kiosk, self-service, finance, transit, conference, education, healthcare, public service, e-commerce, hotels, restaurants, travel service, payment systems, museums, exhibitions, smart home, subways, railway stations, control and operation systems, airports, entertainments, etc.

Industrial Open Frame SAW Touch Monitor Touchscreen 19 Inch Surface Waterproof

FAQ

1. Are you a manufacturer?

Yes, KeeTouch is a professional touch product manufacturer for over 16 years, located in Shenzhen, China.

2. What’s your MOQ for the SAW Touch Monitor?

Our minimum order quantity is 1pc only.

3. What is your warranty period for the SAW Touch Monitor?

Our regular warranty is 12 months for all the products, with 2-3 years Warranty (optional).

4. Can you produce the product according to the customer's requirements?

Sure, with 40+ Professional R & D engineers, OEM and ODM are offered.

5. What is your payment method?

We can accept T/T, Western Union, Paypal, Pay Later, Credit card, Boleto, e-Checking and Alipay. ( L/C can be negotiable. )

6. What is your delivery time for the SAW Touch Monitor?

3-5 work days for inventory orders, 7-15 business days for bulk production.
