Pneumatic Control V Type Floating Type Ball Valve PN10 / 16 CE Certifcation
Pneumatic Control V Type Floating Type Ball Valve PN10 / 16 CE Certifcation
Specifications
Brand Name :
Kelite Valve
Model Number :
DN25~250/500mm,PN10/16/25/40/63
Certification :
ISO, CE,API
Place of Origin :
China
MOQ :
1PC
Supply Ability :
3000-8000PCS per month
Delivery Time :
10-80days
Packaging Details :
Plywood packing or fumigation packing
Size :
DN25~250/500mm
Pressure :
PN10/16/25/40/63
Material :
Stainless Steel
Certifcate :
CE, API,ISO
Operation :
Handle
Description

Pneumatic Control V Type Floating Type Ball Valve PN10 / 16 CE Certifcation

SEGMENT BALL VALVE STAINLESS STEEL V BALL

Technical Data :

Pneumatic Control V Type Floating Type Ball Valve PN10 / 16 CE Certifcation

Specification:

SPECIFICATIONS FOR V TYPE BALL VALVES
Pressure rating and size:
DIN PN10-PN64,ANSI 150LB 300LB
DN25 to DN400
1"~16"
Material:
Body : WCB, CF8, CF8M
Bonnet : WCB, CF8, CF8M
Ball : A105, SS304, SS316
Stem : F6a, SS304, SS316
Seat : EPDM,Metal,Viton,PTFE,NBR
Special material on request.
Operated type
Manual, Pneumatic, Gear, Electric, Bare shaft, etc.
Structure:
V segmented
Flange connection:
EN1092 & ANSI B16.5 & JIS
Type
Flange, wafer
Maximum working temperatures:
Nitril:80°C
NBR:110°C
EPDM:110°C
PTFE:150°C, Metal seat for high temperature

Select us :

  • Design team: With professional design staff, Sample order is always welcomed
  • Professional factory: Specializing in manufacturing valves for many years, competitive price with good quality, the deadline usually is 30-45 days
  • Sample: We can offer sample in 3 days, but the shipment charge is usually beared by customerside, the fee will be deducted from agreed offical order.
  • Quick response to your needs: We will answer within 24 hours, Welcome to contact with us if you have any problems, We are looking forward to cooperating with you.
