Specifications
Brand Name :
RONGSHENG
Model Number :
10101-52-7
Certification :
ISO9001
Place of Origin :
Henan, China
Alkali Resistance :
Good
Shape :
blanket or board
Fire Resistance :
Non-combustible
Packing :
Inside plasric bag
Service Temperature :
1000-1300 degree
Density :
64 kg/m3
Flame Resistance :
Non-flammable
Colour :
white
Flexibility :
Flexible
Size :
600mmX400mmX(10-50)mm
Fiber Diameter :
3-5
Temperature :
1260C
Chemical Content :
Al2O3+SiO2
Thickness :
25mm
Compressive Strength :
0.05 MPa
Description
Product Description
Ceramic fiber board is a high-performance insulation product made of high-purity ceramic fiber by adding the right amount of organic matter and binder. It is flat, ceramic materials are evenly distributed, free of asbestos and environmental protection. ceramic fiber insulation boards solid texture, wind erosion resistance, excellent toughness and other advantages make it an ideal material for kilns, pipes and other insulation types of equipment. It has low thermal conductivity and low thermal storage, and no expansion during heating, which can reduce energy cost and cycle time, and protect the surface of refractory from thermal shock and chemical attack.
Product Advantage

Fire resistant ceramic fiber board advantage:


1, with high temperature thermal conductivity, light weight, long life, tensile strength, good elasticity, non-toxic and so on.
2, high compressive strength, long service life;
3, low heat capacity, low thermal conductivity;
4, non-brittle material, good toughness;
5, the size of accurate, good flatness;
6, easy to install,
7, excellent anti-wind erosion performance;
8, continuous production, fiber distribution, performance and stability;
9, excellent sound and noise reduction performance.
Specification
Type
COM
ST
HP
HA
Zir-Alu
HZ
Classified Temp.
1100ºC
(1983ºF)
1260ºC
(2300ºF)
1260ºC
(2300ºF)
1360ºC
(2480ºF)
1400ºC
(2550ºF)
1430ºC
(2600ºF)
Working Temp.
<1000ºC
(2012ºF)
1050ºC
(1922ºF)
1100ºC
(2012ºF)
1200ºC
(2192ºF)
1200ºC
(1192ºF)
1350ºC
(2462ºF)
Color
white
white
white
white
white
white
Density(kg/m3)
260-320
(16-20lb/ft3)
260-320
(16-20lb/ft3)
260-320
(16-20lb/ft3)
260-320
(16-20lb/ft3)
260-320
(16-20lb/ft3)
260-320
(16-20lb/ft3)
Linear Shrinkage (%)
(24 hrs)
-3
(1000ºC/1832ºF)
-3
(1000ºC/1832ºF)
-3
(1100ºC/2012ºF)
-3
(1250ºC/2282ºF)
-3
(1000ºC/2012ºF)
-3
(1350ºC/2462ºF)



Thermal conductivity
(W/M.K)
0.085
(400ºC/752ºF)
0.132
(800ºC/1472ºF)
0.180
(1000ºC/2012ºF)
0.085
(400ºC/752ºF)
0.132
(800ºC/1472ºF)
0.180
(1000ºC/2012ºF)
0.085
(400ºC/752ºF)
0.132
(800ºC/1472ºF)
0.180
(1000ºC/2012ºF)
0.085
(400ºC/752ºF)
0.132
(800ºC/1472ºF)
0.180
(1000ºC/2012ºF)
0.085
(400ºC/752ºF)
0.132
(800ºC/1472ºF)
0.180
(1000ºC/2012ºF)
0.085
(400ºC/752ºF)
0.132
(800ºC/1472ºF)
0.180
(1000ºC/2012ºF)
Compression Strength
(Mpa)
0.5
0.5
0.5
0.5
0.5
0.5

Chemical(%)
Al2O3
44
46
47-49
52-55
45-46
39-40
Al2O3+SiO2
96
97
99
99
-
-
Al2O3+SiO2+ZrO2
-
-
-
-
99
ZrO2
-
-
-
-
.5-7
15-17
Fe2O3
<1.2
<1.0
0.2
0.2
0.2
0.2
Na2O+K2O
≤0.5
≤0.5
0.2
0.2
0.2
0.2
Size(mm)
1200*1000mm(47″*40″); 1000*600mm(40″*36″);900*600mm(24″*36″)
20-50mm(1″/2″)thickness
