High Temperature Cordierite Mullite Ceramic Batt Plate Refractory Ceramic Mullite Cordierite Slab For Kiln Furniture
High Temperature Cordierite Mullite Ceramic Batt Plate Refractory Ceramic Mullite Cordierite Slab For Kiln Furniture
High Temperature Cordierite Mullite Ceramic Batt Plate Refractory Ceramic Mullite Cordierite Slab For Kiln Furniture
High Temperature Cordierite Mullite Ceramic Batt Plate Refractory Ceramic Mullite Cordierite Slab For Kiln Furniture
High Temperature Cordierite Mullite Ceramic Batt Plate Refractory Ceramic Mullite Cordierite Slab For Kiln Furniture
High Temperature Cordierite Mullite Ceramic Batt Plate Refractory Ceramic Mullite Cordierite Slab For Kiln Furniture
High Temperature Cordierite Mullite Ceramic Batt Plate Refractory Ceramic Mullite Cordierite Slab For Kiln Furniture
High Temperature Cordierite Mullite Ceramic Batt Plate Refractory Ceramic Mullite Cordierite Slab For Kiln Furniture
Specifications
Brand Name :
RONGSHENG
Certification :
ISO9001
Place of Origin :
Henan, China
Fe2O3 Content :
≤ 0.5%
Chemical Composition :
Al2O3: 70-80%, SiO2: 20-30%
Packing :
Wooden Pallets
Refractoriness :
≥ 1790 ℃
Material :
Mullite
Rervice Temperature :
1550
Cold Crushing Strength :
55-60MPa
Flexural Strength :
≥20 MPa
Origin :
Xinmi
Feature :
High Refractoriness, Good Thermal Shock Resistance
Acid Resistance :
Excellent
Usage :
Refractory Material
Density :
2.6 g/cm3
Thermal Shock Resistance :
≥ 300 ℃
Thermal Expansion :
0.5-0.9% under 1000 ℃
Description

Cordierite Mullite Kiln Furniture:

Cordierite-Mullite kiln furniture is composed of cordierite, mullite and glass phase. Due to the high temperature resistance of mullite and the low expansion of cordierite, Cordierite-Mullite kiln furniture has excellent thermal shock resistance,long service time,can be safety used at temperature below 1350℃.


Cordierite Mullite Kiln Furniture Features:

1. Good thermal conductivity 2. Good high temperature strength 3. Wear resistant and erosion resistant 4. Good thermal shock resistance 5. Good corrosion resistance 6. Good oxidation resistance 7. Not easy in deformation and cracking

Cordierite Mullite Kiln Furniture Application

Widely used in the ceramic and glass panel industries. For example, tunnel kilns, shuttle kilns, ceramic kilns, roller kilns, etc.
Item
Unit
BRAND
RS-001
RS-002
RS-003
AI2O3
%
35
39
60
SiO2
%
53
49
35
MgO
%
7.5
8
5
Max Working Temperature
ºC
1280
1260
1350
Bulk Density
g/cm3
1.85
1.82
2.2
Apparent Porosity
%
28
30
22
Coefficient of Thermal Expansion
at 20ºC - 1000ºC
10-6 k-1
2.6
2.2
3.2
Specific Heat at 20ºC
Kj/Kg.k
1
1
1
M.O.R. at 20ºC
MPa
14
11
11
M.O.R. at 1250ºC
MPa
10
10
10
Thermal Shock Resistance
Excellent
Excellent
Excellent
Max Working Temperature
ºC
1280
1260
1350
