900Mhz / 1.2Ghz 5W FPV Video Transmitter VTX Long Distance UAV Video Link
900Mhz / 1.2Ghz 5W FPV Video Transmitter VTX Long Distance UAV Video Link
900Mhz / 1.2Ghz 5W FPV Video Transmitter VTX Long Distance UAV Video Link
900Mhz / 1.2Ghz 5W FPV Video Transmitter VTX Long Distance UAV Video Link
900Mhz / 1.2Ghz 5W FPV Video Transmitter VTX Long Distance UAV Video Link
900Mhz / 1.2Ghz 5W FPV Video Transmitter VTX Long Distance UAV Video Link
900Mhz / 1.2Ghz 5W FPV Video Transmitter VTX Long Distance UAV Video Link
900Mhz / 1.2Ghz 5W FPV Video Transmitter VTX Long Distance UAV Video Link
Specifications
Brand Name :
Kimpok technology
Model Number :
KP-12VTX5W
Certification :
CE/FCC
Place of Origin :
China
MOQ :
1 set
Price :
Negotiaiton
Payment Terms :
T/T, Western Union,PayPal
Supply Ability :
2,000pcs per month
Delivery Time :
3-7 days
Packaging Details :
export standard packing
Product name :
1.2GHz drone video transmitter
Output rf power :
5 Watt
Channel :
8 channels
Interface :
AV
Distance :
40~60km from air to ground
Weight :
90g
Description

900Mhz / 1.2Ghz 5W FPV Video Transmitter VTX Long Distance UAV Video Link

long range drone video transmitter Features:

1. 5W high power amplifier for VTX with a long range transmission
2. Image, color black and white compatible
3. Small size, light weight, easy to carry, good installation
4. Responsive, timely, send and receive real-time transmission
5. Using FM mode, anti-interference ability, good image quality
6. Highly integrated, stable and reliable transmission distance
7. DC power supply, easy to use.
8. Large output frequency, equipped fan in it, credibility, use for long distance wireless transmit projects and special use in military project.

Specification:

Voltage DC 10~36V
Current 1.2A
Frequency 1.2Ghz (1080MHz, 1120MHz, 1160MHz, 1200MHz, 1240Mhz, 1280MHz, 1320MHz, 1360MHz) other frequency is customization
Number of channels 8 CHs
Transmit Power 5 watt
Video Output 1 Vp-p(FM)
Distance (Open environment) 40~60km from air to ground
Overall Configuration Transmitter, video cable, antenna
Temperature -10℃ ~ +50℃
Transmitter Weight 90g
Dimensions (L * W * H) 95x50x20mm

900Mhz / 1.2Ghz 5W FPV Video Transmitter VTX Long Distance UAV Video Link

900Mhz / 1.2Ghz 5W FPV Video Transmitter VTX Long Distance UAV Video Link

900Mhz / 1.2Ghz 5W FPV Video Transmitter VTX Long Distance UAV Video Link

Installing:

A. The line has 5 plugs for connecting transmitter, camera and power supply
One of the line's points connecting to transmitter, another has 4 plugs (red, yellow, white, black)
Red plug connect DC 12V/1000mA, can also connect battery
White and yellow plug connect to camera's audio and video apart
And black one connects camera's power input jack

B. Push the control button, can change the channel of receiver
Meanwhile, push it and last several seconds, can close the digital play and turn into saving power model
Then push it again, can replay
The function can be able to lock channel, so as to avoid mistaking operation

C. Set the same channel with transmitter and receiver

Our Service

1. One-stop ODM/OEM solution;
2. 24-hour technical support;
3. Lifetime maintenance (Replacement parts will be charged after a year);
4. Provide professional system design and construction;

5. 5 engineers provide professional system design and construction;

6. Good prices and Military grade quality with 17 years experience in wireless video transmission field.
