Rugged Metal Industrial Keyboard With Trackball 103 Function Keys And Number Keypad
Rugged Metal Industrial Keyboard With Trackball 103 Function Keys And Number Keypad
Rugged Metal Industrial Keyboard With Trackball 103 Function Keys And Number Keypad
Rugged Metal Industrial Keyboard With Trackball 103 Function Keys And Number Keypad
Rugged Metal Industrial Keyboard With Trackball 103 Function Keys And Number Keypad
Rugged Metal Industrial Keyboard With Trackball 103 Function Keys And Number Keypad
Rugged Metal Industrial Keyboard With Trackball 103 Function Keys And Number Keypad
Rugged Metal Industrial Keyboard With Trackball 103 Function Keys And Number Keypad
Rugged Metal Industrial Keyboard With Trackball 103 Function Keys And Number Keypad
Rugged Metal Industrial Keyboard With Trackball 103 Function Keys And Number Keypad
Rugged Metal Industrial Keyboard With Trackball 103 Function Keys And Number Keypad
Rugged Metal Industrial Keyboard With Trackball 103 Function Keys And Number Keypad
Rugged Metal Industrial Keyboard With Trackball 103 Function Keys And Number Keypad
Rugged Metal Industrial Keyboard With Trackball 103 Function Keys And Number Keypad
Rugged Metal Industrial Keyboard With Trackball 103 Function Keys And Number Keypad
Rugged Metal Industrial Keyboard With Trackball 103 Function Keys And Number Keypad
Rugged Metal Industrial Keyboard With Trackball 103 Function Keys And Number Keypad
Rugged Metal Industrial Keyboard With Trackball 103 Function Keys And Number Keypad
Rugged Metal Industrial Keyboard With Trackball 103 Function Keys And Number Keypad
Rugged Metal Industrial Keyboard With Trackball 103 Function Keys And Number Keypad
Specifications
Place of Origin :
China
Brand Name :
KINGLEADER
Model Number :
MKB-FN103A-TB
Certification :
CE,FCC
MOQ :
1pcs
Price :
US$
Packaging Details :
1pcs/box, 10pcs/ctns
Delivery Time :
20days
Payment Terms :
T/T,Paypal
Supply Ability :
2000pcs/month
Description

Rugged Metal Industrial Keyboard With Trackball 103 Function Keys And Number Keypad

PN:MKB-FN103A-TB

Key Feature:

-103 keys(of them 10-12 function keys), panel mount

-Integrated trackball and numeric keypad;

-Protruding full travel(2.0mm)keys with etched engraved graphics, excellent tactile feedback

-Specially designed to operate in harsh environments, making it ideal for kiosks and other applications in public places.

-Built from stainless steel, high vandal-proof.

-Dust-proof and liquid-proof, meet IP65 requirement
-PS/2 or USB interface, easy to plug into computer directly
-Optical trackball or mechanical trackball for option
-Customizable

Specifications

Material

Front panel & Keys: Brushed stainless steel

Back panel: Aluminum alloy

Trackball: Stainless steel(Dia: 38mm)

Electrical Data

Power supply voltage: DC 5 V 5%

Current rating: 20 mA

Interface: USB or PS2

EMC compliant.
Emission: EN 50081-1
Immunity: EN 50082-1

FCC: Part 15, class B

Safety: EN 60950, CE compliant

Environmental Characteristics

Operating temperature: -20 C to + 60 C

Storage temperature: - 40 C to + 80 C

Saline mist: 96 hours, IEC 60512-6

Damp heat test at + 40 C: 21 days, IEC 60512-6

Dry heat test at + 85 C: 10 days, IEC 60512-6

Mechanical Data

Actuation force for key:120±15g

Key travel: 2.0mm

Lifetime (cycles): Min 5, 000, 000 actuations

Sealing protection: IP65/NEMA4X from the front

Vibration resistance: 5 Hz -200 Hz, IEC 60512-4

Shock resistance: 3 axis 150 m/s - 11 ms, IEC 60512-4

Operation system

PS2: Win NT4, 98SE, 98ME, 2000, XP

USB: Win 98SE, 98ME, 2000, XP, Mac OS9 / OSX

Weight and Dimension

Weight: 2.2kg

Dimension:
Front panel: 478.0 x 135.0 x 32.10mm
Back panel: 502.0 x 159.0 x 32.10mm(Mechanical track-ball)
Back panel: 502.0 x 159.0 x 49.10mm(Optical trackball)

Rugged Metal Industrial Keyboard With Trackball 103 Function Keys And Number Keypad

Rugged Metal Industrial Keyboard With Trackball 103 Function Keys And Number Keypad
