Single Gun 20kW~40kW DC EV Charger Electric Vehicle Level 3 Chargers Ocpp DC Fast Charging Station
Single Gun 20kW~40kW DC EV Charger Electric Vehicle Level 3 Chargers Ocpp DC Fast Charging Station
Single Gun 20kW~40kW DC EV Charger Electric Vehicle Level 3 Chargers Ocpp DC Fast Charging Station
Single Gun 20kW~40kW DC EV Charger Electric Vehicle Level 3 Chargers Ocpp DC Fast Charging Station
Single Gun 20kW~40kW DC EV Charger Electric Vehicle Level 3 Chargers Ocpp DC Fast Charging Station
Single Gun 20kW~40kW DC EV Charger Electric Vehicle Level 3 Chargers Ocpp DC Fast Charging Station
Single Gun 20kW~40kW DC EV Charger Electric Vehicle Level 3 Chargers Ocpp DC Fast Charging Station
Single Gun 20kW~40kW DC EV Charger Electric Vehicle Level 3 Chargers Ocpp DC Fast Charging Station
Single Gun 20kW~40kW DC EV Charger Electric Vehicle Level 3 Chargers Ocpp DC Fast Charging Station
Single Gun 20kW~40kW DC EV Charger Electric Vehicle Level 3 Chargers Ocpp DC Fast Charging Station
Single Gun 20kW~40kW DC EV Charger Electric Vehicle Level 3 Chargers Ocpp DC Fast Charging Station
Single Gun 20kW~40kW DC EV Charger Electric Vehicle Level 3 Chargers Ocpp DC Fast Charging Station
Specifications
Place of Origin :
Guangdong, China
Model Number :
F5-DC1000V-20kW~40k/A
Brand Name :
KIWI
Interface Standard :
CCS1 CCS2 GB/T CHAdeMO
Output Current :
DC
Output Power :
20kW~40k
Input Voltage :
380V
Installation Method :
Wall-mount/Floor stand installation
Start-up and billing method :
App operation and RFID
Input Frequency :
50Hz /60Hz
IP protection level :
IP55
OCPP :
OCPP 1.6J/2.01J
USB :
Upgrade, download
RS485 :
Point to Point communication
Insulation detection :
DC+ and PE, DC- and PE impedance
Connection temperature :
Plug temperature detection
Leakage current detection :
30mA leakage protection switch
MOQ :
5 pieces
Price :
CN¥30,908.98/pieces 5-10 pieces
Description
Single Gun 20kW~40kW DC EV Charger Electric Vehicle Level 3 Chargers Ocpp DC Fast Charging Station
Single Gun 20kW~40kW DC EV Charger Electric Vehicle Level 3 Chargers Ocpp DC Fast Charging Station
Single Gun 20kW~40kW DC EV Charger Electric Vehicle Level 3 Chargers Ocpp DC Fast Charging Station
Single Gun 20kW~40kW DC EV Charger Electric Vehicle Level 3 Chargers Ocpp DC Fast Charging Station
Single Gun 20kW~40kW DC EV Charger Electric Vehicle Level 3 Chargers Ocpp DC Fast Charging Station
Single Gun 20kW~40kW DC EV Charger Electric Vehicle Level 3 Chargers Ocpp DC Fast Charging Station
MODEL
kW-20S
kW-30S
kW-40S
AC Input Power
40A, 400V
60A, 400V
80A, 400V
Input type
3P + N + PE
Input Voltage Range
AC380V~400V
Input Frequency
50Hz /60Hz
THD
≤5%
DC Output Power Rating (MAX)
20kW
30kW
40kW
DC Output Voltage
150-1000VDC
Cable Length
5M or Customized
Cellular Communication
GSM, 4G, LTE
Connectivity
Internet access via 4G/3G/Ethernet (RJ45)
User Authentication
App operation and RFID
User Interface
7 inch LCD high-contrast touchscreen
Communiation Protocols
Proprietary and OCPP 1.6J/2.0
Language System
English, Chinese or Customized
Protection Rating
IP55 and IK10 (cabinet) / IK08 (touchscreen)
Operating Temperature
- 20 °C to 55 °C
Storage Temperature
-40 °C to 70 °C
Humidity
< 95%, non-condensing
Mounting
Wall-mount/Floor stand installation
Dimensions (mm)
263*410*660mm
Net Weight (kg)
≤48kg
Single Gun 20kW~40kW DC EV Charger Electric Vehicle Level 3 Chargers Ocpp DC Fast Charging Station
Single Gun 20kW~40kW DC EV Charger Electric Vehicle Level 3 Chargers Ocpp DC Fast Charging Station
Single Gun 20kW~40kW DC EV Charger Electric Vehicle Level 3 Chargers Ocpp DC Fast Charging Station
Single Gun 20kW~40kW DC EV Charger Electric Vehicle Level 3 Chargers Ocpp DC Fast Charging Station

FQA

Q: How is your electric vehicle charging station after-sale service?
A:1/We will build a whatsapp/skype/wechat service group with technical engineers and company leader if need;
2/We provide 24/7 online service,so you're welcome to contact us any time you need;
3/Will change the part for free during warranty if non-human damage,for other problems,we'd like to supply customer the part at original cost.

Q: How is your payment method?
A: Same as other ev charging stations suppliers,normally 30%-50% deposit and balance paid off before shipment,
special requirement customer please contact us for further discussion.

Q: How long is your normal delivery time?
A: 1/For stock ev charger,can arrange the shipment immediately after you confirm the order;
2/For custom AC ev charger less than 100pcs,normally 7-15 days;
3/For custom DC ev charger less than 100pcs,normally 15-25 days;

Q: Can I use my own card or app at your electric car charging stations?
A: Normally the RFID card and app have to identify our electric charger,so we will provide you 3 free RFID card for each
charger.

Q:Will your electric car charger charging slower in winter?
A:The electric charging station may need a little longer warm up time before normal run,but this is very small change,it won't influence the output power,so we can ignore this influence.

Q:Can you provide a video how to install the electric vehicle charger?
A:Yes we have the installation guide video,it's very easy and anyone who know a little about electricity safety can finish this work,we will also be ready online to help your any possible question.

Q:How can I become your exclusive agency?
A:Only if you have this interest,you can be our agent if we don't have exclusive agent in your market.
if you want to be exclusive agent,we will have an annual sales amount target requirement,welcome to further discuss about more details,we're open to any constructive advice.
