SG-F208C Heavy duty Single Shaft Profiling Milling Machine
SG-F208C Heavy duty Single Shaft Profiling Milling Machine
SG-F208C Heavy duty Single Shaft Profiling Milling Machine
SG-F208C Heavy duty Single Shaft Profiling Milling Machine
SG-F208C Heavy duty Single Shaft Profiling Milling Machine
SG-F208C Heavy duty Single Shaft Profiling Milling Machine
SG-F208C Heavy duty Single Shaft Profiling Milling Machine
SG-F208C Heavy duty Single Shaft Profiling Milling Machine
SG-F208C Heavy duty Single Shaft Profiling Milling Machine
SG-F208C Heavy duty Single Shaft Profiling Milling Machine
Specifications
Brand Name :
KM
Model Number :
SG-F208C
Place of Origin :
china
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
5 Pieces per Month
Delivery Time :
15 days
Packaging Details :
Regular export packing
machine weight :
220kg
LXHXW :
3300mmX1150mmx1650mm
Description

SG-F208C Heavy duty Single Shaft Profiling Milling Machine

SG-F208C Heavy duty Single Shaft Profiling Milling Machine

Product introduction: Product introduction

The equipment is mainly used for aluminum curtain wall profiles and aluminum door and window profiles of various shapes of through hole copying processing, copying the shape of the hole by the proportion of 1:1 to the workpiece through the copying template to achieve copying processing. Spindle adopts CNC special high speed motor, high rotation speed, large button spacing, atomization cooling, can improve the processing finish and prolong the service life of the tool, so it is especially suitable for aluminum alloy profiles and heat insulation aluminum profiles of multi-point keyhole, drilling, milling processing.

Technique data

1, the size of the table... 800mmx260mm

2, the machine power supply... Three-phase 380 vac / 50 hz

3, vertical stroke... 200mm

4, travel up and down... 200mm

5, the spindle motor power... 2.2 kw

6, rotating speed of cutter... 18000r/min

7, pressure cylinder size... Phi 32 x80mm

8, machine pressure... 0.6-0.8 MPa

9, copy board size... 780mmX165mmX6mm

10, the maximum milling cutter diameter... Phi 14

11, the dimensions... 3300mmX1150mmx1650mm

12, machine weight... 220kg
