1.5 SS316 38mm Metal Random Packing Intalox Saddles For Absorbing Tower
1.5 SS316 38mm Metal Random Packing Intalox Saddles For Absorbing Tower
Specifications
Brand Name :
Yuanqiao
Model Number :
Metal Intalox Saddles
Certification :
ISO9001
Place of Origin :
Anping, China
MOQ :
1pc
Price :
Negociation
Payment Terms :
L/C, T/T
Supply Ability :
1000 pcs per month
Delivery Time :
5-10 days
Packaging Details :
Wooden boxes
Product Name :
Metal Random Packing
Material :
Stainless Steel 304, 316L, Etc.
Shape :
Raschig Ring
Size :
16# 25# 40# 50# 70#
Application :
Absorption , scrubbing , stripping
Type :
Catalyst beds
Keyword :
Metal rashing ring
Description

1.5" Ss316 38mm Metal Random Packing Saddle Ring

1.5" Ss316 38mm Metal Random Packing Saddle Ring

Description
Material: Stainless Steel304, Carbon Steel OEM: Yes
Type: As Per Order Wall Thickness: As Per Order
Product Group: Metal Tower Packing Application: Absorption, Scrubbing, Etc.
Packing: Jumbo Bag Service: On Line Service
High Light:

38mm metal random packing

,

1.5" metal random packing

,

saddle ring packing ss316

SS316 1.5" 38mm Stainless Steel Saddle Rings Metal Random Packing

1. Introduction:

Stainless Steel Raschig Super Rings --- Tower Packing New Choice

Now we have a new optimal solution to industry’s demands for modern heavy duty packing, as the introduction of super raschig ring. Different from previous packing shapes, the super raschig ring avoids the droplet formation with large gas loads.
The super raschig ring has 30% more loading capacity, almost 70% lower pressure drop, and 10% higher mass transfer efficiency than conventional metal random packing.

2. Metal Saddle Rings Specification:

38mm Stainless Steel 304 Saddle Ring:

Nominal size38

mm saddle rings

Thickness

0,4 mm

Weight

241 kg/m³

Surface area

170 m²/m³

Void fraction

97 %

Material

stainless steel

Available material

carbon steel, titanium, hastelloy, nickel, copper, aluminium and others on request

3. SS 316L Random Packing Saddle I Ring Advantage:

The metal saddle ring gives one of the best choices for high performance random packing, with low pressure drop and high efficiency. This specially designed saddle-shape random packing provides a lower pressure drop at the same vapor and liquid loads. It can be effectively used in both high pressure and vacuum towers. Others of its advantages include large effective inter-facial area, high mechanical strength and low cost. Metal saddle rings are therefore used in many distillation and absorption columns all around the world. It is available in various sizes, which give different combinations of efficiency and pressure drop.

​

4.Metal Saddle Ring Packing Applications:

  • Rectification towers

  • Separation of organic acid

  • Absorbing tower

  • Desorbing tower

  • Acid Gas Removal

  • Atmospheric and high pressure distillation
