Customizable 10ft Cat6 Utp Cat6 Lan Cable With Rj45 Metal Connector
Customizable 10ft Cat6 Utp Cat6 Lan Cable With Rj45 Metal Connector
Specifications
Brand Name :
KUNCAN
Model Number :
KC-0713
Certification :
USA,CE,RoHS
Place of Origin :
Guangdong, China
MOQ :
500 pieces
Price :
$0.45/pieces 500-999 pieces
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Supply Ability :
1000PCS/Per Week
Delivery Time :
25days
Packaging Details :
PE Bag/pcs
Type :
CAT 6, CAT5/CAT5e/CAT6/CAT7
Number of Conductors :
8
Product name :
Cat6 Lan Cable
Cable gauge :
24AWG/26AWG/28AWG
Color :
Red/White/Black/Grey/Blue/Green
Conductor :
Bare Copper
Length :
10ft
Jacket :
PVC/LSZH
Shield :
UTP/FTP/SFTP
Warranty :
1 year
Description

UTP Cat6 LAN Cable with RJ45 Connectors

550MHz Bandwidth • 10Gbps Ready • 24AWG Bare Copper

TIA/EIA-568-C.2 Certified RoHS Compliant 100% Copper 550MHz Bandwidth
[High-res cable with RJ45 connectors] [Close-up of gold-plated contacts] [Cable cross-section showing twisted pairs]

Technical Specifications

  • Category: Cat6 UTP (Unshielded Twisted Pair)
  • Speed: 10Gbps @ 55m / 1Gbps @ 100m
  • Bandwidth: 550MHz
  • Conductor: 24AWG solid bare copper
  • PoE Support: Up to IEEE 802.3bt (PoE++)
  • Jacket: PVC (CM/CMR) or LSZH options
  • Connectors: Gold-plated RJ45 (8P8C)
  • Impedance: 100Ω ±15%

Available Options

  • Lengths: 0.5m to 305m bulk spools
  • Colors: Blue, Black, White, Red, Green, Yellow
  • Jacket Rating: CM (General), CMR (Riser), CMP (Plenum)

Key Features

10Gbps Performance

Supports 10GBASE-T Ethernet at reduced distances (up to 55m) with backwards compatibility to 1000BASE-T.

Enhanced PoE Support

Delivers up to 90W (802.3bt PoE++) for power-hungry devices like PTZ cameras and WiFi 6 access points.

Precision Engineering

Precisely twisted 4 pairs with differentiated twist rates to minimize NEXT and FEXT interference.

Detailed Technical Specifications

Parameter Specification
Standard Compliance TIA/EIA-568-C.2, ISO/IEC 11801 Class E
Conductor Material 24AWG solid bare copper (±0.002")
DC Resistance ≤ 9.38Ω/100m @ 20°C
Propagation Delay ≤ 548 ns/100m (max)
Attenuation @ 250MHz ≤ 36.6 dB/100m
PSNEXT ≥ 42.3 dB @ 250MHz
Operating Temperature -20°C to 75°C (-4°F to 167°F)
Bend Radius ≥ 8x cable diameter

Recommended Applications

  • Network Infrastructure: 10Gbps switches, servers, NAS devices (up to 55m)
  • PoE++ Systems: High-power devices like PTZ cameras, LED lighting
  • Data Centers: Top-of-rack switching, server interconnects
  • AV Systems: HDBaseT extenders, digital signage
  • Gaming/Streaming: Low-latency connections for competitive gaming

Grey Gold Plated Rj45 Connector With Shield Cat5 Cat6 Cat7 Ethernet Lan Power Network Cable

Product Parameters


Item Factory Price Cat5 Cat5e Cat6 Cat6A UTP FTP Ethernet Network Cable Patch Lan Cable
Category Cat5/Cat5e/Cat6/Cat7
Specification 2 pairs,4pairs,8pairs
Conductor 0.51mm(24AWG),0.4mm(26AWG)
Material Bare copper/CCS/CCA
Jacket PVC/LSZH
Shied

UTP(unshielded twisted pair), FTP(shielded foil twisted pair)

SFTP(shielded foil twisted pair)
Length Custom Made
Color Red/White/Black/Grey/Blue/Green,etc
Certification USA,CE,RoHS
Application Network Modem,LE Plate,Wall Socket,PC
Product Description

What are the details of our products?

Customizable 10ft Cat6 Utp Cat6 Lan Cable With Rj45 Metal Connector

Customizable 10ft Cat6 Utp Cat6 Lan Cable With Rj45 Metal ConnectorCustomizable 10ft Cat6 Utp Cat6 Lan Cable With Rj45 Metal Connector

Customizable 10ft Cat6 Utp Cat6 Lan Cable With Rj45 Metal ConnectorCustomizable 10ft Cat6 Utp Cat6 Lan Cable With Rj45 Metal ConnectorCustomizable 10ft Cat6 Utp Cat6 Lan Cable With Rj45 Metal ConnectorCustomizable 10ft Cat6 Utp Cat6 Lan Cable With Rj45 Metal Connector

Related Products




Buyer Feedback

Customizable 10ft Cat6 Utp Cat6 Lan Cable With Rj45 Metal Connector

FAQ

Q1: Are you factory or trade company?

A: We are factory of more than 16 years export experience.


Q2: What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery.


Q3: What is your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU.


Q4: Samples ?

A : 2-5 pieces free samples are available,fright on you. delivery time usually is 2-3 days. Customized samples will take 5-10days.


Q5: How will you maintain our long-term business relationship?

A: Quality is priority.We will keep offering products good in quality and competitive in price to ensure our customers benefit.


Q6:How to ship out the cargo?
A:At your request, by sea, by air, by express, all are available.
