Black Outdoor IP65 Waterproof Optical Fiber Distribution Box KEXINT FTTH KXT-B-16L4
Black Outdoor IP65 Waterproof Optical Fiber Distribution Box KEXINT FTTH KXT-B-16L4
Black Outdoor IP65 Waterproof Optical Fiber Distribution Box KEXINT FTTH KXT-B-16L4
Black Outdoor IP65 Waterproof Optical Fiber Distribution Box KEXINT FTTH KXT-B-16L4
Black Outdoor IP65 Waterproof Optical Fiber Distribution Box KEXINT FTTH KXT-B-16L4
Black Outdoor IP65 Waterproof Optical Fiber Distribution Box KEXINT FTTH KXT-B-16L4
Black Outdoor IP65 Waterproof Optical Fiber Distribution Box KEXINT FTTH KXT-B-16L4
Black Outdoor IP65 Waterproof Optical Fiber Distribution Box KEXINT FTTH KXT-B-16L4
Black Outdoor IP65 Waterproof Optical Fiber Distribution Box KEXINT FTTH KXT-B-16L4
Black Outdoor IP65 Waterproof Optical Fiber Distribution Box KEXINT FTTH KXT-B-16L4
Black Outdoor IP65 Waterproof Optical Fiber Distribution Box KEXINT FTTH KXT-B-16L4
Black Outdoor IP65 Waterproof Optical Fiber Distribution Box KEXINT FTTH KXT-B-16L4
Specifications
Brand Name :
KEXINT
Model Number :
KXT-16L4
Certification :
CE/ROHS/ISO9001
Place of Origin :
Guangdong，China
MOQ :
10 Pieces
Price :
10 - 99 pieces $15 ; 100 - 499 pieces $13 ; >= 500 pieces $12
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1000 Piece/Pieces per Week
Delivery Time :
7 days
Packaging Details :
Inner Carton+Outer Carton
Color :
Black
Material :
PC+ABS
Cable Port Count :
4 into 8 out
Protection Level :
IP 65
Size :
320*210*85 mm
Splice Tray Count :
3 pieces(Max)
Application :
FTTH FTTB FTTX Network
Connector Type :
SC FC LC ST
Package :
Carton Box
Warranty Time :
2 Years
Description

KEXINT FTTH KXT-B-16L4 36 Cores Outdoor IP 65 Black Fiber Optic Distribution Box

The equipment is used as a termination point for the feeder cable to connect with drop cable in FTTx communication network system.The fiber splicing, splitting, distribution can be done in this box, and meanwhile it provides solid protection and management for the FTTx network building.

Black Outdoor IP65 Waterproof Optical Fiber Distribution Box KEXINT FTTH KXT-B-16L4

Features:
1. Total enclosed structure

2. Material: PC+ABS,wet-proof,water-proof,dust-proof,anti-aging, protection level up to IP 65.
3. Clamping for feeder cable and drop cable, fiber splicing, fixation, storage, distribution...etc all in one.
4. Cable,pigtails,and patch cords are running through their own paths without disturbing each other, micro type PLC splitter installation, easy maintenance.
5. Distribution panel can be flipped up, feeder cable can be placed by expression port,easy for maintenance and installation.
6. Box can be installed by the way of wall-mounted or poled-mounted,suitable for both indoor and outdoor use.
Black Outdoor IP65 Waterproof Optical Fiber Distribution Box KEXINT FTTH KXT-B-16L4
Model Number
KXT-B-16L4
IP Level
IP 65
Max Capacity
3*12 cores splice tray
Mounting Way
Wall/Pole mounting
Material
PC+ABS
Size
320*201*85 mm
Color
Black
Cable Diameter
18 mm(Max)
Port Count
4 into 8 out

Black Outdoor IP65 Waterproof Optical Fiber Distribution Box KEXINT FTTH KXT-B-16L4

Noted:

1. Environmental requirement
Working temperature:-40℃～+85℃
Relative humidity:≤85%(+30℃)
Atmospheric pressure:70 Kpa～106 Kpa
2. Main technical datasheet
Insertion loss:≤0.15 dB
UPC return loss:≥50 dB
APC return loss:≥60 dB
3. Thunder-proof technical datasheet
The insulation resistance between the grounding device and the metal parts of the box is no less than 2 MΩ/500 V(DC); IR≥2 MΩ/500 V
The voltage resistance between the grounding device,and the box and its metal parts is no less than 3000 V(DC)/min, no puncture,no flash over; U≥3000 V
