CE Oil Lubrication 4500l/S Turbo Molecular Pump
CE Oil Lubrication 4500l/S Turbo Molecular Pump
Specifications
Brand Name :
KYKY
Model Number :
F-400/3500B
Certification :
CE
Place of Origin :
China
MOQ :
1
Payment Terms :
T/T
Delivery Time :
4weeks
Packaging Details :
polywood box for oversea shipment
Flange :
ISO-K DN400
cooling :
Water
lubrication :
Oil
Ultimate pressure :
2E-6 Pa
Pumping capacity :
4500L/s
name :
CE Oil Lubrication 4500l/S Turbo Molecular Pump
Description

Turbo Molecular Pump , F-400/4500 , Large pumping speed, Water cooling , Oil lubrication

KYKY developed the newest oil lubrication turbo pumps of convenient operation, flexible installation, wide application range and stable performance. pumping capacity is 4500 L/s ( N2).

Specifications:

Flange(In) DN400 ISO-K Gas Throughout (sccm) N2:5500
Flange(Out) KF DN100 He:4000
Pumping Speed( L/s) N2:4500 H2:3200
He:3200 Ar:2100
H2:2000 Rotation Speed ( rpm) 15300
Ar:4200 Run-Up Time(min) ≤10
Compression Ratio N2:5*107 Cooling Type,Standard Water
He:103 Cooling Water Consumption ( L/min) ≥1
H2:5*102 Cooling Water Temperature(℃) ≤25
Ar:5*107 Power Connection:Voltage (V AC) DC24/AC220
Ultimated Pressure(Pa) ≤2×10-6 Max.Power Consumption (W) ≤1100
Max. Continuous Fore-vacuum pressure(Pa) 100 Controller Model FD-III
Max. Fore-vacuum Pressure N2:300 Backing pump 30L/s

Advantages:

This series of pump is good at performance under harsh environmental (high temperature, dust, etc.), stable in performance and with long service life, and simple maintenance and convenient operation as well.

Applications:

Main applications are in industrial leak detection, PVD, CVD, ion implantation, vacuum electronic components manufacturing, low-E glass, ITO glass, optical coating, solar cells, electron beam welding, vacuum furnace and other industries


KYKY TECHNOLOGY CO., LTD. has many years of experiences in R & D and manufacturing of vacuum generation products, including series molecular pumps, series molecular pump stations, series ion pumps, series gate valves and supporting controllers.

Since developing the first vertical turbo molecular pump in 1970’s, KYKY always orients

to the demand-driven market, aims to meet the requirement of our customers, and continuously launches new products in the enterprise spirit of developing on innovation.
