Portable Digital Aerosol Photometer For Cleanroom Biological Cabinet Leak Detection
Portable Digital Aerosol Photometer For Cleanroom Biological Cabinet Leak Detection
Specifications
Brand Name :
SRL
Model Number :
APM-350
Certification :
ISO 9001
Place of Origin :
CHINA
MOQ :
1set
Price :
8000-10000USD
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, Paypal
Supply Ability :
100sets per month
Delivery Time :
5-10 working days
Packaging Details :
Carton case
Standard :
NSF49, IEST, ISO14644, EN61010-1:2010, EN61326-1:2006
Function :
Leakage detection in cleanroom, clean bench
Instrument type :
Portable
Industry :
Biological, electronics, research
Description

The Aerosol photometers are primarily used to check for small pinholes and other damage in filter media, such as frame seals, gasket seals, and leaks in the filter frame. By checking the tightness of the high-efficiency filter and its connection with the installation frame, find the defects of the high-efficiency filter itself and its installation in time, and take corresponding remedial measures to ensure the cleanliness of the area.

APM-350 can automatically switch between upstream and downstream aerosol concentrations to determine whether there is a leak in the filter. The portable scanning probe enables the operator to quickly and accurately find the leak point in remote locations and determine other leakage ratios. When the alarm line is exceeded, the display panel will An alarm will be displayed.

Features

Reasonable structure design, small size, easy to carry

The host adopts a 5-inch color touch screen, which is more convenient for operation and faster in data processing.

Visual display of data such as leak rate and pump sampling speed

Portable scanning probe, 3.5-inch color display, one-key operation, synchronous display with the host interface, convenient for users to observe the test results

Automatically switch upstream and downstream

In order to ensure reliable and stable data, imported air pump and light source are used

Applications

HEPA filter verification

Equipment certification, equipment monitoring

Biological safety cabinet, clean workbench

Semiconductor industry

Pharmaceutical industry, electronics industry

Medical operating room, clean room

Pharmaceutical packaging and manufacturing

Food processing, scientific experiments

Specifications

Model APM-350
Data display range 0.0001%-100.0% colorful LCD display
Dynamic Range 0mg/m3～120mg/m3
Accuracy 1% of reading (0.01% to 100%)
Repeatability 0.5% of reading (0.01% - to 100%)
Flow control 1cfm (28.3L/min)±10%
Auto zero Auto-zero at startup
Call the police When the preset limit is exceeded, 2 modes of sound and visual alarm can be selected
Report Continuous mode, storage mode (6000 sets of data can be stored), print mode
Aerosol Type PAO, DOP
Standard NSF49, IEST, ISO14644, EN61010-1:2010, EN61326-1:2006
Power supply AC 220V 50/60Hz
Dimensions 258(L)x178(W)x360(D)
Net Weight 10.3kg(including scan probe)
