Integrated Distillation Apparatus Device Unit 6 Station Biochemistry Instruments
Integrated Distillation Apparatus Device Unit 6 Station Biochemistry Instruments
Specifications
Brand Name :
SRL
Model Number :
ZL-S6
Certification :
ISO 9001
Place of Origin :
China
MOQ :
1set
Price :
USD 500-1000
Payment Terms :
D/A, D/P, T/T, Western Union, Online, L/C, Paypal
Supply Ability :
200sets per month
Delivery Time :
5-10 working days
Packaging Details :
wooden case
Application :
Laboratory
Supply area :
Global
Shipping way :
Sea, land, air
Station number :
6
Display :
LCD
Distillation flask :
500ml
Description

Intelligent LCD display integrated distillation apparatus 6 station

The intelligent integrated distillation apparatus integrates constant temperature heating, automatic control of distillation end point, and cooling water circulation.
Using far-infrared ceramic heating device, intelligent distillation end point control, built-in cooling water automatic cooling and reflux device, and professionally designed condenser tube and other technologies Features. Easy to use, energy saving and environmental protection.

Features

1. Double control function of automatic detection of distillation end point, automatic stop of heating, high degree of automation;
2. The closed cooling water automatic cooling and circulating return device does not need external tap water cooling, saving energy and reducing consumption;
3. The far-infrared ceramic heating device is used to replace the ordinary electric heating furnace or electric heating mantle, which is more energy-saving, has good waterproof effect and is resistant to acid and alkali corrosion;
4. 6 sets of samples can be made at one time, and single hole and single temperature can be controlled;
5. Large LCD display heating temperature and heating time;
6. Automatically stop the heating function, and the working time can be set arbitrarily;
7, with anti-suck back function. (When making cyanide and sulfur dioxide, the distillate outlet is inserted below the absorption liquid level, which is easy to suck back)

Specifications

Model ZL-S6F ZL-S6S
Cooling function Built-in air cooling device External water cooling device
Compressor / Yes
Distillation endpoint control Heating + timing control, with weighing function
Sample unit Standard 6, single hole single temperature control (other samples can be customized)
Heating method Far-infrared ceramic heating (no open flame heating, waterproof)
Cooling method Closed internal circulation return system, no need for external cooling water source
Distillation endpoint control The distillation end point is controlled by weighing and time
Temperature control Single hole independent automatic temperature control
Large LCD screen digital display temperature control Room temperature-400 degree C; (temperature adjustable)
Time control 0~200min adjustable
Heating time 5~8min
Distillation speed 12ml/min
Distillation flask specifications 500mlx6
Distillate receiving bottle 250mlx6
Anti-suck back With anti-vacuum solenoid valve, with anti-suck back function
Leakage protection device protected
Rated voltage 220V/50HZ
Single furnace heating power 0~450W
Maximum heating power 0~2700W
Dimensions 980x520x370mm
