Cryogenic Cool Air Small Lab Ball Mill Grinding Machine 2L For Laboratory Pulverizing
Cryogenic Cool Air Small Lab Ball Mill Grinding Machine 2L For Laboratory Pulverizing
Cryogenic Cool Air Small Lab Ball Mill Grinding Machine 2L For Laboratory Pulverizing
Cryogenic Cool Air Small Lab Ball Mill Grinding Machine 2L For Laboratory Pulverizing
Cryogenic Cool Air Small Lab Ball Mill Grinding Machine 2L For Laboratory Pulverizing
Cryogenic Cool Air Small Lab Ball Mill Grinding Machine 2L For Laboratory Pulverizing
Cryogenic Cool Air Small Lab Ball Mill Grinding Machine 2L For Laboratory Pulverizing
Cryogenic Cool Air Small Lab Ball Mill Grinding Machine 2L For Laboratory Pulverizing
Specifications
Brand Name :
MITR
Model Number :
XH-YXQM-2L
Certification :
ISO9001:2008/CE
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
TT,Western union
Supply Ability :
10set per week
Delivery Time :
7-15 working days
Packaging Details :
Export Standard Wooden Package
Product Name :
Small Lab Ball Mill
Application :
Pharmaceuticals,food,geology,metallurgy,agriculture,glass,ceramics,aviation chemicals,biology,materials,lithium power,electronics,plants, biology and so on.
Power :
220V 50HZ
Dimesion :
78*58*69cm/120kg
Jar Volume :
50ml-500ml
Revolution :
5-400r/min
Rotation :
10-800r/min
Feeding size :
Soil material≤10mm,others ≤3mm
Discharging size :
minimum down to 0.1μm
Degree :
0-30℃
Description

Cryogenic Cool Air Small Lab Ball Mill Grinding Machine 2L For Laboratory Pulverizing

Application:

It is widely used Pearl, ginseng, Dendrobium candidum, tablets, medicament, liquorice, coke, coal, glass, cellulose, paper, chip, polymer, pigment, metal oxide, iron ore, iron powder, aluminum powder, magnesium powder, ceramics, Alumina, bone, kaolin, Limestone, gypsum, quartz, minerals, ores, carbonized fibres, graphite, ink, clay minerals, fibre products, sewage sludge, catalysts, chemicals, alloys, soils, waste samples, wood, plant materials, Cement slag, concrete, slag, tobacco.

Feature:

  • Oil seal mute technology
  • Elegant design, easy to operate
  • Ideal for wet or dry grinding application
  • Automatic and programmable control with LED display
  • Multiple grinding modes to choose
  • High Uniformity and excellent repeatability
  • Fast rotational speed, high efficiency and fine granularity
  • Digital display of the actual rotational speed of the grinding jar
  • Four samples with different sizes and materials in one experiment
  • Programmable interval and pause times and grinding sequences
  • Stepless speed regulation, reversing function
  • Smaller grinding jars also possible with an adapter
  • Gear-drive offers an effective solution to problems caused by belt driving
  • Safety stirrup lock, easy to install and disassemble.

Cryogenic Cool Air Small Lab Ball Mill Grinding Machine 2L For Laboratory Pulverizing

7.When carrying, there are universal wheels to push and run;When operating, there are universal supporting feet for stable.

Cryogenic Cool Air Small Lab Ball Mill Grinding Machine 2L For Laboratory Pulverizing

8.The temperature could be down to 0-30℃ with circulating cold air .

Cryogenic Cool Air Small Lab Ball Mill Grinding Machine 2L For Laboratory Pulverizing

Technical parameter:

Model Spec Grinding jar matching Quantities Air condition Speed (revolution ) Speed rotation Power Temperature range
XH-XQM1L 1L 50-250ml 2 or 4 2P 10-450 20-900 220v 0-30℃
XH-XQM2L 2L 50ML-500ml 2 or 4 2P 10-400 10-800 220v 0-30℃
XH-XQM4L 4l 50-1L 2 or 4 2P 10-400 10-800 220v 0-30℃
XH-XQM8L 8L 2L 2 or 4 2P 10-320 20-640 220v 0-30℃
XH-XQM12L 12L 3L 2 or 4 3P 10-320 20-640 380v 0-30℃
XH-XQM16L 16L 4L 2 or 4 3P 10-280 20-560 380v 0-30℃
XH-XQM20L 20L 5L 2 or 4 3P 10-280 20-560 380v 0-30℃
XH-XQM40L 40L 10L 2 or 4 3P 10-220 20-440 380v 0-30℃
XH-XQM60L 60L 15L 2 or 4 3P 10-180 20-360 380v 0-30℃


Ball Mill Jars And Ball Mill Grinding Media

Our factory can provide 304 stainless steel jar,Tungsten carbide jar(YG8),ceramic jar,alumina jar,zirconia jar,agate jar.Nylon jar, Polyurethane jar, PTFE jar.we can also provide grinding media stainless steel,ceramic,corundum,alumina,zirconia,agate,tungsten carbide.

Cryogenic Cool Air Small Lab Ball Mill Grinding Machine 2L For Laboratory Pulverizing
Cryogenic Cool Air Small Lab Ball Mill Grinding Machine 2L For Laboratory Pulverizing

Join an exhibition

Cryogenic Cool Air Small Lab Ball Mill Grinding Machine 2L For Laboratory Pulverizing

Company Information

Changsha Mitrcn instrument equipment Co., Ltd specializes in designing, manufacturing and selling experimental equipment. Supported by the state key laboratory of Central South University Powder Metallurgy with Hunan University, Shanghai Jiao tong University and other well-known universities to maintain long-term close technical exchanges and product development cooperation.

The high-tech talents in our company are: doctor, master, eight senior engineer,eight senior technician, ten engineer,six technician.The main business is the R&D, production and sale of experimental equipment and related technical consultation services.

Our factory shops:

Cryogenic Cool Air Small Lab Ball Mill Grinding Machine 2L For Laboratory Pulverizing

Our company office:

Cryogenic Cool Air Small Lab Ball Mill Grinding Machine 2L For Laboratory Pulverizing

Packaging & Shipping

Cryogenic Cool Air Small Lab Ball Mill Grinding Machine 2L For Laboratory Pulverizing
