Eco-Friendly Alumina Grinding Balls for Sustainable Grinding Solutions Wear Resistance

●Chemical Composition:

●Typical Properties:

● Sizes Φ:

● Features:

u High density, high hardness, low wear loss, regular shape, impact resistance, corrosive resistance;

u20-40times wear-resistance more than natural ball and common ball, and can improve 40--60% grinding efficiency.

● Applications:

u High hardness and high viscosity material, such as zircon sand, silicon dioxide, calcite (GCC), magnetic bands coatings for audio and video tapes, paint, coating, pigment, Ceramic glaze, titanium dioxide and so on.

u Wet grinding including batch mill and continuous ball mill.

●Package:

25KG/woven bag,1000KG-1250KG for one pallet with shrink wrapped

● Notice:

1. Avoid Contamination:

   • Keep the balls clean and free from dust, grease, or other contaminants, especially in precision applications like bearings or grinding.

2. Proper Storage:

   • Store in a dry, clean environment to prevent moisture absorption or contamination. Use protective packaging if necessary.

3. Temperature Limits:

   • Alumina ceramic balls can withstand high temperatures (up to 1600°C), but avoid sudden thermal shocks to prevent cracking.

4. Compatibility Check:

   • Ensure the balls are compatible with the operating environment, including chemical exposure, load, and speed conditions.

5. Load Capacity:

   • Do not exceed the recommended load capacity for the balls, as excessive stress can lead to failure.

6. Installation Precision:

   • Use proper techniques and tools during installation to avoid misalignment or damage, especially in bearing applications.

7. Avoid Abrasive Contact:

   • While alumina is highly wear-resistant, avoid contact with extremely abrasive materials that could cause surface damage over time.

8. Regular Inspection:

   • Periodically inspect the balls for signs of wear, cracks, or surface damage, especially in high-stress applications.

9. Do Not Use in Impact-Intensive Applications:

   • Alumina ceramic balls are not suitable for applications involving heavy impact or shock loads, as they may fracture under such conditions.

10. Follow Manufacturer Guidelines:

    • Adhere to the operating instructions and recommendations provided by the manufacturer for optimal performance and safety.

11. Avoid Chemical Incompatibility:

    • While alumina is chemically resistant to most substances, verify compatibility with specific chemicals in your application.

12. Use Appropriate Lubrication (if required):

    • In bearing applications, ensure proper lubrication to reduce friction and wear, even though alumina has a low friction coefficient.

13. Replace Worn-Out Balls:

    • Replace balls that show significant wear or damage to maintain system efficiency and prevent failure.

14. Consult Experts for Special Applications:

    • For unique or extreme applications, consult with material experts or the manufacturer to ensure proper selection and use.

15. Avoid Excessive Vibration:

    • Excessive vibration can cause wear or damage to alumina ceramic balls. Ensure proper alignment and balance in the system.

16. Do Not Use in High-Impact Grinding:

    • While alumina balls are excellent for grinding, avoid using them in high-impact grinding applications where steel balls might be more suitable.

17. Check for Surface Defects:

    • Before use, inspect the balls for surface defects such as cracks, chips, or irregularities that could affect performance.

18. Use in Suitable Equipment:

    • Ensure the equipment (e.g., ball mills, bearings) is designed to handle ceramic balls and their specific properties.

19. Monitor Wear in Grinding Applications:

    • In grinding applications, regularly monitor the wear of alumina balls and replace them when they become too small or worn to maintain efficiency.

● FAQ:

1. What are alumina ceramic balls made of?

   • They are made from aluminium oxide (Al₂O₃), a high-purity ceramic material known for its hardness and wear resistance.

2. What are the key properties of alumina ceramic balls?

   • High hardness, excellent wear resistance, chemical stability, high-temperature resistance (up to 1600°C), and electrical insulation.

3. What are alumina ceramic balls used for?

   • They are used as grinding media, bearing components, valve balls, and in applications requiring wear resistance and chemical inertness.

4. Why choose alumina balls over steel or other ceramics?

   • They offer superior wear resistance, chemical stability, and are lighter than steel, making them ideal for specific applications.

5. What sizes are available for alumina ceramic balls?

   • Sizes typically range from 1mm to several inches, depending on the application.

6. Can alumina balls withstand high temperatures?

   • Yes, they can operate in temperatures up to 1600°C (2912°F) without losing their properties.

7. Are alumina balls chemically resistant?

   • Yes, they are resistant to most acids, alkalis, and corrosive substances, making them suitable for harsh environments.

8. Are alumina balls suitable for food or medical applications?

   • Yes, they are non-toxic, chemically inert, and biocompatible, making them ideal for food, pharmaceutical, and medical applications.

9. How do I clean alumina ceramic balls?

   • Clean them with water, solvents, or ultrasonic cleaners, depending on the application. Ensure they are completely dry before reuse.

10. Can alumina balls be reused?

    • Yes, they can be reused multiple times if they are not excessively worn or damaged.

11. What is the lifespan of alumina ceramic balls?

    • Their lifespan depends on the application, operating conditions, and load. Proper use and maintenance can extend their life significantly.

12. Are alumina balls brittle?

    • While they are hard and durable, they can fracture under heavy impact or shock loads. Avoid using them in impact-intensive applications.

13. What industries use alumina ceramic balls?

    • They are used in mining, chemicals, pharmaceuticals, paints, coatings, electronics, and precision engineering industries.

14. How do I store alumina ceramic balls?

    • Store them in a dry, clean environment to prevent contamination or moisture absorption.

15. What is the cost of alumina ceramic balls?

    • They are more cost-effective than silicon nitride balls and offer excellent performance for many applications.

16. Can alumina balls cause contamination?

    • They are highly wear-resistant, but prolonged use may cause minimal wear. Regular inspection is recommended to avoid contamination.

17. What is the density of alumina ceramic balls?

    • The density is approximately 3.6-3.9 g/cm³, making them lighter than steel balls.

18. Are alumina balls electrically conductive?

    • No, they are electrically insulating, making them suitable for electrical and electronic applications.

19. Can alumina balls be customized?

    • Yes, we can customize size, tolerance, and surface finish to meet specific application requirements.

20. How do I select the right alumina balls for my application?

    • Consider factors like load, speed, temperature, chemical exposure, and precision requirements. Consult with the us if needed.

21. Are alumina balls suitable for wet grinding?

    • Yes, they are suitable for both wet and dry grinding processes.

22. What is the hardness of alumina ceramic balls?

    • They have a hardness of approximately 9 on the Mohs scale, making them one of the hardest ceramic materials.

23. Can alumina balls be used in high-speed applications?

    • Yes, they are suitable for high-speed applications due to their low density and high wear resistance.

24. Do alumina balls require lubrication?

    • In bearing applications, lubrication may be required to reduce friction and wear, depending on the operating conditions.

25. What is the difference between alumina and zirconia balls?

    • Alumina balls are harder and more cost-effective, while zirconia balls offer higher toughness and density, making them suitable for more demanding applications.
