Forceps Pinching Force Testing Equipment Customization Medical Use
Forceps Pinching Force Testing Equipment Customization Medical Use
Forceps Pinching Force Testing Equipment Customization Medical Use
Forceps Pinching Force Testing Equipment Customization Medical Use
Specifications
conforms to :
YY / t0686-2017 Appendix B
The test range of kneading force :
0-20n
error :
not more than ± 1%
Tension loading speed :
70mm/min
Printing mode :
print 2-10 times of test average data and its total average value and deviation value.
name :
6Medical forceps pinching force tester customization
Place of Origin :
China
Brand Name :
KeRang
Certification :
Calibration Certificate (Cost Additional)
MOQ :
1 SET
Price :
Negotiable
Packaging Details :
plywood
Delivery Time :
30 days
Payment Terms :
L/C,L/T
Supply Ability :
10 set /month
Description

6 Medical forceps pinching force tester customization

5.7 inch (120 × 90) single color LCD touch screen and Chinese menu display are adopted. Nominal specification, classification, setting load, printing, testing, uplink, downlink, time, calibration. The menu on the LCD is controlled by the keyboard, the tension is loaded automatically, the data is recorded automatically, the tension and peak force data are displayed in real time, the data report is output automatically, and ten test reports are printed on board.

This product fully conforms to: YY / t0686-2017 Appendix B

The test range of kneading force is 0-20n, the error is not more than ± 1%, and the resolution is 0.01N;

Tension loading speed: 70mm/min, error no more than ± 1mm

Printing mode: print 2-10 times of test average data and its total average value and deviation value.

Plots: plots showing force values versus time

Net weight: 11kg overall dimension: 400 × 290 × 275 (mm).

Partial list:

1. One host

2. Printing paper 1 roll

3. A set of clamps

4. A set of weights

5. One year warranty

6. Operating instructions

Production Line

With years of development, we have established perfect sales network and integrated after-sale service system at domestic and abroad, which enables the company to provide timely, accurate and efficient services, and won good customer reputations. The products are sold all over in China and exported to more than 30 countries and regions such as Europe, America, Southeast Asia, South America, Middle East and Africa. The production, sales volume and scale are all ranked first in the same industry.
