Silicon Communication Test Equipment , Laser Radiation Monitoring System NOVA II
Silicon Communication Test Equipment , Laser Radiation Monitoring System NOVA II
Specifications
Name :
Laser Radiation Monitoring System
Detector Type :
silicon
Aperture :
φ10mm
Noise Level for filter out pW :
200
Response Time with Meter s :
0.2
Fiber Adapters Available (see page 63) :
FC, ST, SC, SMA
Place of Origin :
China
Brand Name :
KeRang
Certification :
Calibration Certificate (Cost Additional)
MOQ :
1 SET
Price :
Negotiable
Packaging Details :
plywood
Delivery Time :
30 days
Payment Terms :
L/C,L/T
Supply Ability :
10 set /month
Description

Laser Radiation Monitoring System NOVA II

Standard:Confirm to IEC60950,IEC60825-2,IEC60825-12.

Application:Used to measure the laser wavelength, aperture, power generated by laser or LED.

Test sample:Laser or LED components.

Parameters:

OPHIR Laser power meter probe PD300R-3W
Detector Type silicon
Aperture φ10mm
Filter mode Filter out Filter in
Spectral Range nm 350-1100 430-1100
Power Range 100mW to5nW 100mW to5nW
Power Scales 100mW to 300nW and dBm 3W to 30mW and dBm
Resolution nW 0.1 NA

Maximum Power vs.

Wavelength

 nm mW mW
<488 100 3000
633 100 3000
670 100 2000
790 100 1200
904 100 1200
1064 100 2200
Accuracy (including errors due to temp. variations)
% error vs Wavelength nm ±10 360-400 NA
±3 400-950 ±5 430-950
±5 950-1100 ±7 950-1100
Damage Threshold W/cm2 10 100
Max Pulse Energy μJ 20 500
Noise Level for filter out pW 200
Response Time with Meter s 0.2
Beam Position Dependence ±2% ±3%
Fiber Adapters Available (see page 63) FC, ST, SC, SMA
