Specifications
Brand Name :
kerang
Model Number :
DC-1
Certification :
certification
Place of Origin :
CHINA
MOQ :
1SET
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
20 sets/month
Delivery Time :
50days
Packaging Details :
plywood
Material :
Q235
weight :
200kg
color :
white
size :
1200mm*1000mm
purpose :
Dust test
Description

Sand And Dust Test Chamber

Product information:

Sand and dust test chamber is designed and manufactured in accordance with the standard requirement of IEC60529. It is applicable to do the dust proof test of all kinds of electric and electronic products used on the environmental condition of sand dust.

Technical parameters:

Item parameter
Input voltage AC 220V±10 % 50Hz&120V 60HZ
Metal mesh diameter Ф50µm
screen stencil diameter 75µm
Dust used in the test Dry talcum powder which can go through olfactory foramina
Dust concentration Dust capacity of the chamber is 2Kg /m³
Airflow velocity The maximum is no more than 2m / S
Testing time 0.01s~99 hours 99mins,preset arbitrarily
Speed of evacuation of vacuum pump ≤1litre/1s Adjustable arbitrarily.
Power ≤1500W
Environmental condition

Temperature:0~40℃

Relative humidity:≤85%RH

No fierce shaking, impacting, vibrating. No dust and corrosive air
Outer box size L*W*H=1000mm×1100mm×1650mm
Internal box size L*W*H=800mm×800mm×800mm
