Compound Trinocular Biological Microscope 1600X Bright Field 6 Kg Weight
Compound Trinocular Biological Microscope 1600X Bright Field 6 Kg Weight
Compound Trinocular Biological Microscope 1600X Bright Field 6 Kg Weight
Compound Trinocular Biological Microscope 1600X Bright Field 6 Kg Weight
Specifications
Brand Name :
NO
Model Number :
B200
Certification :
ISO9001, ISO14001, ISO13485, CE, RoHs
Place of Origin :
China
MOQ :
1unit
Price :
Discuss
Payment Terms :
T/T
Supply Ability :
10000 units per year
Delivery Time :
10-20 work days
Packaging Details :
Carton
Head :
Trinoucular
Objective :
Archromatic or Plan
C-mount :
1X, 0.5X
Eyepiece :
10X-18mm
Illumination :
LED or Halogen
Weight :
6 kgs
Description

B203 Trinocular Compound 1600X Bright Field Biological Microcope Compound Trinocular Biological Microscope 1600X Bright Field 6 Kg WeightCompound Trinocular Biological Microscope 1600X Bright Field 6 Kg Weight

The B series trinocular compund biological microscope is widely in the fields of school teaching, biological laboratory, medical laboratory etc.The biological compound microscope can observe samples on computer through a digital microscope camera.This trinocular biological microscope supplys high definite and resolution image.It is a professional lab optical light microscope.

  • Anti-mildew and anti-fogging
  • High quality finite optcal system
  • High brightness LED illumination,with long working life and low power
  • Trinocular head can capture sample image by adding a digital camera or

Compound Trinocular Biological Microscope 1600X Bright Field 6 Kg Weight

Items Specification B203LED B204LED
Eyepiece WF 10×-18 mm(Pointer is optional) ●● ●●
WF 10×-18 mm(adjustable, 0.1 mm) ○ ○
WF 16×-13 mm ○ ○

Achromatic

Objective

 4× ●
10× ●
40×(S) ●
100×/1.25 (Oil) (S) ●
20× ○
60× (S) ○
Plan Objective 4× ●
10× ●
40×/0.65 (S) ●
100×/1.25 (Oil) (S) ●
Monocular Head Inclined 30°, Rotatable 360°

Seidentopf

Trinocular Head

Inclined 30°,Rotatable 360°,

Interpupilary Distance 48-75mm,

Light Distribution 20:80

 ● ●
Nosepiece Quadplex ● ●
Focusing Knobs

Coaxial Coarse and Fine Focusing Knobs

Travel Range: 22mm, Scale: 2µm

 ● ●
Mechanical Stage

Stage Size:125mm×115mm,

Travel: 35mm×75mm

 ● ●
Condenser Abbe N.A. 1.25(Iris Diaphragm) ● ●
Dark Field Ring Available For 4×-40× Objective ○ ○
Polarizing Attachment Analyzer / Polarizer ○ ○
Mirror Plano-concave mirror ○ ○
C-mount 1x/ 0.5X(Focus Adjustable)
Base 3WLED Illumination Systems ● ●

3WLED Illumination Systems

(rechargeable)

 ○ ○

12V 20W Halogen Lamp,

Wide Voltage: 100V-240V

 ○ ○

Note: "●"In Table Is Standard outfits, "○" Is Optional Accessories.

Compound Trinocular Biological Microscope 1600X Bright Field 6 Kg Weight

Compound Trinocular Biological Microscope 1600X Bright Field 6 Kg Weight
