Intelligent Elongation Test Equipment according to IEC60851-3 for Copper Wires
Intelligent Elongation Test Equipment according to IEC60851-3 for Copper Wires
Intelligent Elongation Test Equipment according to IEC60851-3 for Copper Wires
Intelligent Elongation Test Equipment according to IEC60851-3 for Copper Wires
Intelligent Elongation Test Equipment according to IEC60851-3 for Copper Wires
Intelligent Elongation Test Equipment according to IEC60851-3 for Copper Wires
Intelligent Elongation Test Equipment according to IEC60851-3 for Copper Wires
Intelligent Elongation Test Equipment according to IEC60851-3 for Copper Wires
Specifications
Brand Name :
AI
Model Number :
AISC-5
Certification :
ISO
Place of Origin :
CHINA
MOQ :
1 Set Elongation Test Equipment
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
100 sets per month
Delivery Time :
15 days
Packaging Details :
Elongation Test Equipment packed in plywood case
Test Standard :
GB/T4074.3-2008,IEC60851-3
Test object :
copper wires covered with φ0.018-φ3.000mm enamel
Start distance between two clamps :
200±0.5mm
Stretching speed of sample :
300±60mm/min
Maximum elongation testing range :
≥80%
Power supply :
AC220V±10% 50Hz
Power consumption :
≤200W
Overall Dimension :
640×420×410mm
Weight :
45KG
Display :
LED
Description

Performance Characteristics

  • Executive standard: GB/T4074.3-2008/IEC60851-3; Inspection standard: JB/T4279.3-2008
  • This Elongation Test Equipment is used to test elongation (ductility) of copper wires covered with φ0.018-φ3.000mm enamel, silk or other insulation materials and other metal wires with tensile strength ≤2000N;
  • This Elongation Test Equipment adopts SCM control for fast operation and strong anti-interference capacity;
  • Clamps are designed according to characteristics of various wires to prevent samples from breaking at clamp jaws, easy to load samples and, after samples are compressed, enamel can be automatically broken;
  • While sample is broken, movable clamp would automatically stop moving, with error between displayed and actual elongation value less than 1%;

Major Technical Parameters

Start distance between two clamps 200±0.5mm
Stretching speed of sample 300±60mm/min
Maximum elongation testing range ( displacement distance of movable clamp) ≥80% (≥160mm)
Display of elongation LED display, display accuracy of 0.1%
Input power AC220V±10% 50Hz
Power consumption ≤200W
Overall dimensions L×W×H 640×420×410mm
Weight 45kg
