BIFMA X5.1 Office Chair Seat Forward Stability Test Chamber
BIFMA X5.1 Office Chair Seat Forward Stability Test Chamber
BIFMA X5.1 Office Chair Seat Forward Stability Test Chamber
BIFMA X5.1 Office Chair Seat Forward Stability Test Chamber
BIFMA X5.1 Office Chair Seat Forward Stability Test Chamber
BIFMA X5.1 Office Chair Seat Forward Stability Test Chamber
Specifications
Brand Name :
huaxiang
Model Number :
TNJ-023
MOQ :
1 SET
Price :
contact saler
Payment Terms :
L/C, T/T
Delivery Time :
7-10 days
Packaging Details :
Plywood box
Place of Origin :
Dongguan ,China
Supply Ability :
10 sets per month
Description

BIFMA Furniture Testing Equipment Office Chair Seat Forward Stability Tester

Application

The Chair Stability Tester is used to perform the forwards overbalancing test.
Principle
Put the test-piece on the test table, blocked the front leg, apply specified force with forward 20N applied at seat loading point, check the article tends to oventurn forward or not to determine the test-piece forward stability performance.

Install the loading basket under the table which is lifting by Pneumatic actuator, max loading capacity up to 150kg, the lift of cylinder is controlled by pneumatic attenuation device, Load-bearing basket adopt rubber cushioning device to ensure that fall to final position will not produce damage, the operation unit of table can control loading basket to rise or go down, dynamical movement can position device adjustment, easy to operation.


Specification

Seat surface loading: Max: 600N, cumulative
Tensile force: 20N
Loading point position: seat surface center position,60mm from front edge
Seat surface loading pad: diameter: 200mm
camber surface: R300mm,9 pins
Loading rob: , 19mm
both ends A type: sphere SR19mm B type: sharp surface 45 °
Weights basket lifting: manual control
Dimensions (WxDxH): 100x140x105cm
Weight: 500kg
Air source: 6kgf/cm2 stable air source
Standards: ANSI/BIFMA X5.1-12.4 Front Stability;EN 1022, EN 1729-2
