20x12x10cm Rubber Testing Machine Multifunctional 10kg Durable
20x12x10cm Rubber Testing Machine Multifunctional 10kg Durable
Specifications
Brand Name :
Lixian
Model Number :
HZ-7010
Certification :
CE/ISO
Place of Origin :
China
MOQ :
1 set
Price :
USD 500~1000/ per set
Payment Terms :
L/C, T/T, D/A, D/P, Western Union, MoneyGram
Supply Ability :
500 sets/per month
Delivery Time :
5~8 days
Packaging Details :
Standard export wooden case
Model :
HZ-7010
Rubber specimen :
Ф28.68(D)12.7mm
Foam plastic :
50*50*25mm
Septum thickness :
7.62mm,8.89mm,9.52mm,10.16mm
Dimension :
20*12*10cm
Weight :
10kg
Description

Rubber Testing Machine Distortion Of Permanent Comprssion Testing Machine

Equipment Overview

The determination of vulcanized rubber machine applies a constant strain compression deformation of the test method. This test is compressed to the provisions of vulcanized rubber specimens under a high, after a certain temperature and time, or media infiltration, the determination of the rate of the sample compression set.

Test Fixture:
1. Compression required smooth surface, its finish is not less than 7
2. Compression plateu deformation in the test should not be proposing to adopt a steel plate, measuring about 75mm, width 50mm, thickness is 10mm.
3. Limiter height of 8 ± 0.02mm, 7 ± 0.02mm, 6 ± 0.02mm.
4. Incubator should have a continuous blast device, box test temperature uniformity. Temperature test area inside the temperature fluctuation range: 100 ℃ The following is ± 1 Centigarde, 100 ~ 200 Centigrade to ± 2 Centigarde.

Technical parameter:

Model HZ-7010
Rubber specimen Ф28.68(D)12.7mm
Foam plastic 50*50*25mm
Septum thickness 7.62mm,8.89mm,9.52mm,10.16mm
Dimension 20*12*10cm
Weight 10kg
