Automatic 150W Bursting Strength Tester , Multifunctional Burst Testing Machine
Automatic 150W Bursting Strength Tester , Multifunctional Burst Testing Machine
Automatic 150W Bursting Strength Tester , Multifunctional Burst Testing Machine
Automatic 150W Bursting Strength Tester , Multifunctional Burst Testing Machine
Automatic 150W Bursting Strength Tester , Multifunctional Burst Testing Machine
Automatic 150W Bursting Strength Tester , Multifunctional Burst Testing Machine
Automatic 150W Bursting Strength Tester , Multifunctional Burst Testing Machine
Automatic 150W Bursting Strength Tester , Multifunctional Burst Testing Machine
Specifications
Brand Name :
Lixian
Model Number :
HZ-3014
Certification :
CE, ISO
Place of Origin :
China
MOQ :
1
Price :
USD 800~3500 Set
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
200 sets per month
Delivery Time :
7 work days
Packaging Details :
Wooden case
Oil pressure gauge :
0～35 ㎏/㎝ 2
Motor :
AC220V 90W
Dimension :
About 53 ㎝×23.5 ㎝×57 ㎝
Weight :
65kg
Power supply :
1∮，AC220V，1A
Power consumption :
About 150W
Description

Leather Testing Equipment Computer Type Automatic Rupture Strength Tester ISO-2759

Leather Test Equipment Summary

HZ-3014 is suitable for testing the burst strength of base paper, corrugated board, leather, cloth, synthetic leather, etc. This machine is a fully automatic bursting strength testing machine. It only needs to put in the sample, that is, automatic detection, automatic test, automatic oil pressure return and automatic calculation, storage of test data and printing. As an important basis for controlling the quality of finished products, it is an indispensable equipment for quality inspection.
Leather Test Equipment Corresponding Standard
ISO-2759, GB-6545, JIS-P8112, L1018, ASTM-D2210, TAPPI-T403

Leather Test Equipment Applicable Industry

This machine is suitable for the burst strength test of leather, cloth and cardboard.

Leather Test Equipment Technical Parameters

Item Specification
Induction method Pressure transducer
Instruction mode Computer+software type
Accessories HP computer+HP color printer
Software Lixian Special test software
Unit

Can be show as: kgfpsikpa

A,psi: means the force in pounds per inch

B,Kgf: means the force value is kg/cm 2

C,kpa: means the force unit is kPa

Note :The unit to which the indicator light points is the unit of the value displayed on the current force value screen.
Capacity(option) High pressure type 0～100㎏/㎝2(accuracy: 0.1kg/cm2)
Low pressure type 0～16㎏/㎝2(accuracy: 0.1kg/cm2)
Clamp ring diameter Up ring High pressure: Φ31.5mm, low pressure :Φ30.48mm
Down ring High pressure: Φ31.5mm, low pressure: Φ31.75mm
Oil pressure gauge 0～35㎏/㎝2
Motor AC220V　90W
Dimension About 53㎝×23.5㎝×57㎝
weight About 65㎏
Power supply 1∮,AC220V,1A
Power consumption About 150W
Automatic 150W Bursting Strength Tester , Multifunctional Burst Testing MachineAutomatic 150W Bursting Strength Tester , Multifunctional Burst Testing Machine

Automatic 150W Bursting Strength Tester , Multifunctional Burst Testing Machine

FAQ
Q1: What is your warranty ?
A: 12 months product warranty, but lifetime for services. Free Non-consumable components will be provided if any performance failure occurs within 12 months, caused by non-human damage.

Q2: How-to video provided ?
A: Yes. If required, our engineers will record a specialized how-to video for you.

Q3: Are your company a trading one or a factory?
A: Yes, we are a manufactured factory & trade (integration).15 years focusing on test instruments field. Six years exporting experience, warmly welcome to visit our plant (factory), we also support OEM and ODM.

Q4: After an order is placed, when to deliver?
A: Generally about 15 days. If we have inventory, we can arrange shipment within 7 days. Please be aware that our production lead times depend on specific items and item quantities.

Q5: What about the after-sales service and product’s quality?
A: 12 months warranty. After the warranty, the professional after-sale service team will provide perfect technical support. And help the customer solve problems encountered while using our product, handles problems and complaints professionally and timely.Each of the instruments must be carried out 100% quality examination and test when shipping and delivery goods. Product use training, each of our product provide video training to show you how to install & operate. Engineers would be to go abroad for training and repairing.

Q6: What about the packing of equipment?
A: Covered with air bubble film before put the machine into the standard exporting wooden case, which not only has good shock absorption, impact resistance, heat SSO has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
