100L Constant Temperature And Humidity Chamber Multiscene Fireproof
100L Constant Temperature And Humidity Chamber Multiscene Fireproof
100L Constant Temperature And Humidity Chamber Multiscene Fireproof
100L Constant Temperature And Humidity Chamber Multiscene Fireproof
100L Constant Temperature And Humidity Chamber Multiscene Fireproof
100L Constant Temperature And Humidity Chamber Multiscene Fireproof
Specifications
Brand Name :
lixian
Model Number :
HZ-2012A
Certification :
CE
Place of Origin :
China
MOQ :
1
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Delivery Time :
7 days
Packaging Details :
wood
Price :
negotiate
Supply Ability :
negotiate
Corresponding standard ： :
SJ/T10187-91Y73, SJ/T10186-91Y73, IEC68-2-14
Temprature range :
-77 degree ~+205 degree
System :
2-zone transition by vertical transfer of specimens
Material :
Stainless steel
Application :
Industry,Auto Part
Dimensions :
Customer Required
Service :
OEM ODM
Standard :
GB ASTM AISI DIN BS,ASTM,ISO
Color :
Customer Required
Size :
Customized size
Description

Exhaust Heat Rate 12600 KJ/H (3000 Kcal/H) Temperature Impact Chamber

Chamber summary:
The thermal shock test chamber, also known as the high and low temperature impact test chamber, is known as the cold and thermal impact machine in Taiwan. It is used to test the degree of material structure or composite material that can be tolerated in a continuous environment.
Specification:
Model
HZ-2012 Water-cooled
System
2-zone transition by vertical transfer of specimens
Performance *1

Test area
Hot exposure range
＋ 60℃ to ＋ 205℃
Cold exposure range
−77℃ to 0℃
Temp. fluctuation *2
± 1.0℃
Hot chamber
Pre-heat upper limit
＋ 205℃
Heat-up time *3
Within 90 min from ambient temp.
to ＋ 200℃ (Setting: ＋ 205℃)
Cold chamber
Pre-cool lower limit
−77℃
Pull-down time *3
Within 90 min from ambient temp. to −77℃ (Setting: −77℃)

Temp. recovery performance (2-zone)

Recovery conditions
・Hot exposure: ＋150°C (setting: ＋155°C 30 min)
・Cold exposure: − 65°C (setting: − 68°C 30 min)
・Sensor position: downstream
・Specimen: Plastic molded ICs, 10kg
Temp. recovery time
Specimen temp. within 15 min
Transfer time between hot & cold chambers
Within 10 seconds

Ambient recovery

Recovery conditions
・Hot exposure: ＋150℃ to max. ＋ 55℃
・Ambient temp.: ＋ 23℃
・Specimen: Plastic molded ICs, 10 kg
Ambient temp. recovery time
Within 90 min
Inside dimensions
W710×H345×D410 mm
Test area capacity
100 L
Load capacity of test area *4
30 kg
Outside dimensions *5
W1100×H1885×D1965 mm
Weight
Approx. 1100 kg
Utility requirements
Ambient temp. range
＋ 5℃ to ＋ 40℃
Power supply
(Voltage fluctuation: rating ± 10%)
200V AC
3φ 3W 50/60Hz
208V AC
3φ 3W 60Hz *6
220V AC
3φ 3W 60Hz
380V AC
3φ 4W 50Hz
400/415V
AC
3φ 4W
50Hz *7
Piping connection size
Carbon steel pipe, ID 32 mm
Cooling water temp. range
＋ 5℃ to ＋ 38℃
Main function:
Used in electrical and electronic components, automation components, communication components, auto parts, metals, chemical materials, plastics, etc., defense industry, aerospace, military industry, BGA, PCB base board, electronic chip IC, semiconductor ceramics and polymer materials.
The difference between two boxes and three boxes:
The two slots are composed of a cold box and a hot box, the box does not move, and the sample is tested in the manner that the hanging bar is switched between the cold box and the hot box. The three tanks are composed of a cold box, a hot box and a test box, and are tested by means of air flow conversion of the object to be tested and the cold box and the hot box.
Corresponding standard :
1,GB/T2423.1-1989
2,GB/T2423.2-1989
3,GB/T2423.22-1989
4,GJB150.5-86
5,GJB360.7-87
Application industry:
Applicable to aviation, military, ship, electrician, electronics, instrumentation; medical equipment; civil nuclear energy; colleges and universities; research institutes; commodity inspection and arbitration, technical supervision departments; building materials ceramics; petrochemical products, complete machines and parts High and low temperature impact test.
