Baby Cot Guardrail Compression & Pull Push Testing Machine Force Value Accuracy 1% Side Force Cylinder Force Range 0-300n
Baby Cot Guardrail Compression & Pull Push Testing Machine Force Value Accuracy 1% Side Force Cylinder Force Range 0-300n
Baby Cot Guardrail Compression & Pull Push Testing Machine Force Value Accuracy 1% Side Force Cylinder Force Range 0-300n
Baby Cot Guardrail Compression & Pull Push Testing Machine Force Value Accuracy 1% Side Force Cylinder Force Range 0-300n
Baby Cot Guardrail Compression & Pull Push Testing Machine Force Value Accuracy 1% Side Force Cylinder Force Range 0-300n
Baby Cot Guardrail Compression & Pull Push Testing Machine Force Value Accuracy 1% Side Force Cylinder Force Range 0-300n
Specifications
Brand Name :
Lixian
Model Number :
HZ-1230
Certification :
CE, ISO
Place of Origin :
China
MOQ :
1
Price :
USD 190~8000/per set
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
200 sets per month
Delivery Time :
7 work days
Packaging Details :
Wooden case
Application :
infant car
Model :
HZ-1230
Side force cylinder force range :
0-300n
Lateral position of cylinder :
Adjustable
Position of electric vertical force device :
Can be adjusted arbitrarily
Force value accuracy :
1%
Control system :
Programmable controller
Display screen :
Touch screen
Description

Baby Cot Guardrail Compression & Pull Push Testing Machine Force Value Accuracy 1% Side Force Cylinder Force Range 0-300n

Baby Cot Guardrail Compression & Pull Push Testing Machine Equipment summary:

Baby Cot Guardrail Compression & Pull Push Testing Structural principle: The machine consists of a workbench, an aluminum alloy frame, a lateral force device, a vertical force device, a vertical adjustment device and a top cross slide. The workbench lateral force device, vertical force device, vertical adjustment device and top cross slide are fixed on the aluminum alloy frame. During the test, the position of the cross slide is adjusted in two directions by the motor, the position of the lateral force device is adjusted, and the required force is adjusted. The force sensor displays and records the force value..

Baby Cot Guardrail Compression & Pull Push Testing Machine Test Method Details

1. Press down the center of the top fence with a force of 30kg, and press on all sides for one minute.

2. Pull the fence slats with a force of 15kg and hold for 15 seconds.

3. Pull out the middle layer of the fence roof with a force of 20kg, and pull the fence in all directions.

4. Push the short face outside the center of the roof fence 30 times, pushing with a force of 30kg every 5 seconds.

Machine structure diagram (for reference only)

Baby Cot Guardrail Compression & Pull Push Testing Machine Force Value Accuracy 1% Side Force Cylinder Force Range 0-300n

Technical Parameters

Model HZ-1230
Side force cylinder force range 0-300n
Lateral position of cylinder Adjustable
Position of electric vertical force device Can be adjusted arbitrarily
Force value accuracy 1%
Control system Programmable controller
Display screen Touch screen
Number of tests, sequence of actions Can be set arbitrarily
Display force value, number, retention time, displacement Can be set
Structural material Aluminum frame
