Sand and Dust Testing Environmental Test Chamber LCD Touch Screen
Sand and Dust Testing Environmental Test Chamber LCD Touch Screen
Sand and Dust Testing Environmental Test Chamber LCD Touch Screen
Sand and Dust Testing Environmental Test Chamber LCD Touch Screen
Sand and Dust Testing Environmental Test Chamber LCD Touch Screen
Sand and Dust Testing Environmental Test Chamber LCD Touch Screen
Sand and Dust Testing Environmental Test Chamber LCD Touch Screen
Sand and Dust Testing Environmental Test Chamber LCD Touch Screen
Specifications
Brand Name :
Haida
Model Number :
HD-E706
Certification :
CE,,ISO
Place of Origin :
China
MOQ :
1
Price :
Negotiation
Payment Terms :
L/C, T/T, D/A, D/P, Western Union, MoneyGram
Supply Ability :
300 Sets per Month
Delivery Time :
20 days after order confirmed
Packaging Details :
each set protected with resin fiber and PP film, then put into Strong wooden case with operation man
External size :
170 * 150 * 190cm (approx.)
Air pressure :
86~106kpa
Studio temperature :
RT~60'C, adjustable
Powder type :
Talcum powder
Aspirator flowing quantity :
0~6L/min
Testing time :
0~999h88m99s, adjustable
Blowing dust cycle :
Interval control, adjustable
Door material :
Tempering glass
Power supply :
AC380V, 50/60Hz, three phase
Chamber material :
SUS#304 stainless steel
Description

Sand and Dust Testing Environmental Test Chamber with LCD Touch Screen

Haida Burst Strength Tester.pdf

Product Description:

Sand and Dust Testing Chamber Environmental Test Chamber LCD Touch Screen is designed for sealing performance test and reliability test, widely used in electrical, electronics, automobile, motorcycle, LED and other products. It is suitable for the work ability test on the shell sealing performance, product in dust free settlement, in the environment without apparent air flow or with a strong blast air and a large amount of sand dust, and similar conditions.

Main Technical Parameters of Sand and Dust Testing Chamber Environmental Test Chamber LCD Touch Screen

Item

Specification

Inner chamber size

120 * 120 * 120cm

External size

170 * 150 * 190cm (approx.)

Air pressure

86~106kpa

Studio temperature

RT~60'C, adjustable

Amount of talcum powder

2kg per cubic meter of the test chamber volume

Can not have been used for more than 20 tests

Powder type

Talcum powder

Aspirator flowing quantity

0~6L/min

Pressure tolerance

0~2kpa

Metal net size

Wire diameter 50um, width of a gap between wires 75um

Testing time

0~999h88m99s, adjustable

Blower

Centrifugal fan

Blowing dust cycle

Interval control, adjustable

Chamber material

SUS#304 stainless steel

Door material

Tempering glass

Control interface

LCD touch screen

Vacuum system

Pressure gauge, air filter, Pressure regulating FRL, connecting pipe, Vacuum pump

Weight

400kg

Power supply

AC380V, 50/60Hz, three phase

Features of Sand and Dust Testing Chamber Environmental Test Chamber LCD Touch Screen

1. Formed using CNC machining box, nice shape, and no reaction by the handle, easy to operate.


2. Imported high grade stainless steel inner tank (SUS304) mirror panels, use of A3 steel box outside the gall spray, increasing the appearance of the texture and cleanliness.


3. Equipment containing dust vertical circulation of air, dust can be reused for testing; device itself has a good sealing performance, test, laboratory test can clearly observe the situation; device equipped with a vacuum system to meet the needs test; equipment dust the bottom of the device can be replaced.


4. Large observation window with bright lights to keep the box, and use of tempered glass embedded heating element, at any time a clear observation box condition.


5. Test with 50mm diameter holes for the external test power line or signal line.

Chamber Structure:

1, Chamber material: SUS#304 stainless steel;

2, Transparent window is convenient to observe specimen during testing;

3, Blow fan adopts stainless steel shell, high sealing and wing speed, low noise;

4, Inside the shell is the funnel type, vibration cycle can be adjusted, dust free float in the sky falling to blowing the hole together.

Sand and Dust Testing Chamber Environmental Test Chamber LCD Touch Screen ​ view:

Sand and Dust Testing Environmental Test Chamber LCD Touch Screen
