Specifications
Brand Name :
HAIDA
Model Number :
HD-A502S-900
Certification :
ISO 9001:2000; ISO 9001:2008
Place of Origin :
Guangdong, China (Mainland)
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram,In cash, escrow
Supply Ability :
30 Sets per Month Haida
Delivery Time :
5-8 work days
Packaging Details :
ach set protected with resin fiber and PP film, then put into Strong wooden case with operation man
Power :
Electronic
Use :
Packaging containers
Gross Weight :
120kg
Packaging Dimensions :
(WxDxH) 900*700*1250 MM
Description

Computer Servo Packing Carton Compression Test Machine Safety Features

MACHINE PRODUCTION

Box Compression Test Machine is specialized for testing the compression performance of cartons. Generally, suitable for compression test, deformation test and stacking test of the corrugated cartons, honeycomb boxes an etc packages. Also, it will be usage for the compression test of containers (such as plastic drums for edible oil, mineral water), paper canisters, paper boxes, paper cans, container drums and etc.

Computer Servo Packing Carton Compression Test Machine Safety Features

STANDARD FEATURES

Item Description
Max. Force 1000KG(10KN)
Load cell 1 load cell for highest accuracy
Control system Windows 7, RS-232 interface
Motor Panasonic servo motor w/ DC variable speed drive system, high-precision mechanical ball screw rod
Force reading kgf, Ibf, N, KN, T etc
Load cell Resolution 1/250,000
Load Precision within ±0.25%
Parallelism of Platens Parallel within ±2.5mm
Effective test area 700*900*900mm
Test speed 10 ±3mm/min (0.01~200mm/min adjustable)
Software TM 2101
Data display Load, displacement, speed, loading rate and elapsed time
Safety features

E-Stop

Over-load protection

Upper and lower limit switches

Load sensor with automatic retreat

Computer Servo Packing Carton Compression Test Machine Safety Features

HAIDA INTRODUCTION

Founded in 2004, Haida® is the recognized Dongguan, China market leader in the testing equipment industry, having four main manufacture series: Accelerated Environmental Series , Universal Tensile Machine , Paper & Packaging , Foam, Furniture & Optical, also involved in Textile & Shoes & Leather, Luggage, Baby carriage & toys, and optical testing equipment.
