Specifications
Brand Name :
LangO
Model Number :
LMD-400 LMD-600
Certification :
CE ISO9001
Place of Origin :
China
MOQ :
1 set
Payment Terms :
T/T
Model :
LMD-400 LMD-600
Cutting Length (C) :
150-460 mm 230-625 mm
Bag Length (H) :
145-455 mm 225-620 mm
Bag Width (L) :
70-280 mm 70-280 mm
Gusset (W) :
20-100 mm 20-100 mm
Standard flap (P) :
12-20 mm 12-20 mm
Price :
Negotiation
Delivery Time :
15-30days
Description

Vest Bag Flexible Letter Gravure Printing Machine 6 Kw Cold Glue Roller Coating​

Specifications:

Main Technical Parameter
Type LMD-400 LMD-600
Cutting Length (C) 150-460 mm 230-625 mm
Bag Length (H) 145-455 mm 225-620 mm
Bag Width (L) 70-280 mm 70-280 mm
Gusset (W) 20-100 mm 20-100 mm
Standard flap (P) 12-20 mm 12-20 mm
Max. Speed 400 pcs/min 400 pcs/min
Max. reel weight 400 Kg 400 Kg
Max.Roll Diametr 1000 mm 1000 mm
Reel inner diameter 76 mm 76 mm
Paper specification 30-80 gsm 30-80 gsm
Web edge control system Double photoelectric automatic correction control system
Web tension control system automatic constant tension control system
Coating way Cold glue roller coating
automatic counting system YES YES
Automatic oil supply system YES YES
Air pressure ≥0.12cmm, 0.6~1.2Mpa ≥0.12cmm, 0.6~1.2Mpa
Driven motor Double servo motor Double servo motor
Power 6 kw 6 kw
Weight 3000 Kg 3200 kg
Overall dimension 4580X1650X1850 mm 4680X1650X1850 mm

Description:

Introduce sensitization resin as flexible printing plate, suitable for printing such packing materials as polyethylene, polypropylene bag, cellophane and roll paper,etc. It is a kind of ideal printing equipment for producing paper packing bag for food,supermarket handbag, vest bag and clothes bag, etc.

1. simple operating, soft starting, accurate color register.

2. meter counter can set printing quantity, automatic shutdown, automatic stop-off material.

3. pneumatic landing plate cylinder, automatically mixing ink after lifting.

4. the knurled cylinder with ink, ink evenly.

5. Reliable drying system coordinated with high-speed operation, automatic shutdown circuit.

6. 360 degrees continuous and adjustable longitudinal photo checking device.

7. frequency control, adapt to different printing speeds.

8. the roller seats and rewind shelves are loaded moving and stop buttons, easy to operate when the machine is installed.

Vest Bag Flexible Letter Gravure Printing Machine 6 Kw Cold Glue Roller CoatingVest Bag Flexible Letter Gravure Printing Machine 6 Kw Cold Glue Roller CoatingVest Bag Flexible Letter Gravure Printing Machine 6 Kw Cold Glue Roller Coating

Applications:

This machine is suitable for printing such packing materials as polyethylene, polypropylene plastic bag, glass paper and roll paper, etc. And it is a kind of ideal printing equipment for producing paper packing bag for food, supermarket handbag, vest bag and clothes bag, etc.

Competitive Advantage:

- High Speed

- Low price

- Stable quality

- labor cost saved

- maintainers easily

Why choose us?
1. We are the famous science and technology professional enterprise specialized in researching, developing, manufacturing and selling of Bag Making Machines, Paper Bag Making Machine, Film Blowing Machine, Side Weld Bag Making Machine, Paper Slitting Machine, Non Woven Bag Making Machine, Side Sealing Bag Making Machine, Flexographic Printing Machine, Gravure Printing Machine, Paper Cup Making Machine, Tissue Paper Making Machine, Automatic Bag Making Machine, Carry Bag Making Machine, with best quality control, best service .
2. 100% QC inspection and debugging Before Shipment.
3. 100% rest assured after-sales service.

Our service
Pre-Sales Service:
According to your need of actual situation and budget, our professional sales team will provide professional consultation and best solution with strong technical support.(such as raw paper purchasing suggestion, jumbo roll dimension needed, packing ways for transportation, suitable machine and processing craft recommendation with detailed explanation especially in embossing and lamination, etc.)

After-Sales Service:
1. We also provide the door to door abroad installation, equipment debugging, technical training service;
2. Warranty:1 year quality assurance
3. Building customer files, solving various technical problems for user;
4. Our technical team give you 100% rest assured global presence service even over the warranty period.
