Vest Bag Flexible Letter Gravure Printing Machine 6 Kw Cold Glue Roller Coating
Specifications:
Main Technical Parameter | ||
Type | LMD-400 | LMD-600 |
Cutting Length (C) | 150-460 mm | 230-625 mm |
Bag Length (H) | 145-455 mm | 225-620 mm |
Bag Width (L) | 70-280 mm | 70-280 mm |
Gusset (W) | 20-100 mm | 20-100 mm |
Standard flap (P) | 12-20 mm | 12-20 mm |
Max. Speed | 400 pcs/min | 400 pcs/min |
Max. reel weight | 400 Kg | 400 Kg |
Max.Roll Diametr | 1000 mm | 1000 mm |
Reel inner diameter | 76 mm | 76 mm |
Paper specification | 30-80 gsm | 30-80 gsm |
Web edge control system | Double photoelectric automatic correction control system | |
Web tension control system | automatic constant tension control system | |
Coating way | Cold glue roller coating | |
automatic counting system | YES | YES |
Automatic oil supply system | YES | YES |
Air pressure | ≥0.12cmm, 0.6~1.2Mpa | ≥0.12cmm, 0.6~1.2Mpa |
Driven motor | Double servo motor | Double servo motor |
Power | 6 kw | 6 kw |
Weight | 3000 Kg | 3200 kg |
Overall dimension | 4580X1650X1850 mm | 4680X1650X1850 mm |
Description:
Introduce sensitization resin as flexible printing plate, suitable for printing such packing materials as polyethylene, polypropylene bag, cellophane and roll paper,etc. It is a kind of ideal printing equipment for producing paper packing bag for food,supermarket handbag, vest bag and clothes bag, etc.
1. simple operating, soft starting, accurate color register.
2. meter counter can set printing quantity, automatic shutdown, automatic stop-off material.
3. pneumatic landing plate cylinder, automatically mixing ink after lifting.
4. the knurled cylinder with ink, ink evenly.
5. Reliable drying system coordinated with high-speed operation, automatic shutdown circuit.
6. 360 degrees continuous and adjustable longitudinal photo checking device.
7. frequency control, adapt to different printing speeds.
8. the roller seats and rewind shelves are loaded moving and stop buttons, easy to operate when the machine is installed.
Applications:
This machine is suitable for printing such packing materials as polyethylene, polypropylene plastic bag, glass paper and roll paper, etc. And it is a kind of ideal printing equipment for producing paper packing bag for food, supermarket handbag, vest bag and clothes bag, etc.
Competitive Advantage:
- High Speed
- Low price
- Stable quality
- labor cost saved
- maintainers easily
Why choose us?
1. We are the famous science and technology professional enterprise specialized in researching, developing, manufacturing and selling of Bag Making Machines, Paper Bag Making Machine, Film Blowing Machine, Side Weld Bag Making Machine, Paper Slitting Machine, Non Woven Bag Making Machine, Side Sealing Bag Making Machine, Flexographic Printing Machine, Gravure Printing Machine, Paper Cup Making Machine, Tissue Paper Making Machine, Automatic Bag Making Machine, Carry Bag Making Machine, with best quality control, best service .
2. 100% QC inspection and debugging Before Shipment.
3. 100% rest assured after-sales service.
Our service
Pre-Sales Service:
According to your need of actual situation and budget, our professional sales team will provide professional consultation and best solution with strong technical support.(such as raw paper purchasing suggestion, jumbo roll dimension needed, packing ways for transportation, suitable machine and processing craft recommendation with detailed explanation especially in embossing and lamination, etc.)
After-Sales Service:
1. We also provide the door to door abroad installation, equipment debugging, technical training service;
2. Warranty:1 year quality assurance
3. Building customer files, solving various technical problems for user;
4. Our technical team give you 100% rest assured global presence service even over the warranty period.
