20mA Stable Side View LED SMD 1206 Green 570nm Color Multi Function
20mA Stable Side View LED SMD 1206 Green 570nm Color Multi Function
20mA Stable Side View LED SMD 1206 Green 570nm Color Multi Function
20mA Stable Side View LED SMD 1206 Green 570nm Color Multi Function
Specifications
Brand Name :
BOSMFC
Model Number :
Side view 1206 green SMD LED
Certification :
Rohs, Reach
Place of Origin :
China
MOQ :
3000pcs
Payment Terms :
T/T, Western Union, paypal
Supply Ability :
500KK/month
Delivery Time :
5-15 days
Packaging Details :
3000pcs/reel, Reel+Anti-static bag+carton
Application :
Indoor/Outdoor Lighting
Power Dissipation :
60mW
Color :
green light
Wavelength :
520-535nm
Luminous Intensity :
450-900 mcd
Forward Current :
20mA
Forward Voltage :
2.8-3.6v
Size :
3.0*1.0*1.5mm
Warranty :
3 Years
Chip brand :
San'an chip/ Epistar chip
Package :
3000pcs/reel
Lifetime :
50000h
Operating Temperature :
-40℃~85℃
Reverse Voltage :
5V
Storage Temperature :
-40℃~100℃
Description

Side view 1206 green color chip SMD LED Fast Delivery Super Competitive Price RoHS certification

Features:

  1. Long life span, lower Maintenance Cost, RoHS compliant
  2. CHIP 1206 package, inter reflector, high flux output Fast Turn-on time, high current capability
  3. Wide Viewing Angle, ideal for backlight and light pipe application
  4. Available on tape and reel (8mm tape), suitable for automatic placement requipment, reflow and wave solder processes

Technical Parameters:

Electrical optical characteristics :(Ta=25°C)

Parameter Symbol Color Min Typ Max Unit Test Condition
Wavelength λd Green 520 --- 535 nm IF=20mA
Luminous intensity Iv Green 450 --- 900 mcd IF=20mA
Forward voltage VF Green 2.8 --- 3.6 V IF=20mA
Viewing angle --- 120 --- deg IF=20mA
Reverse current IR --- ---- 5 uA IF=20mA
Operation Temperature －40~+85℃ Size 3.0*1.0*1.5mm
Storage Temperature －40~+100℃ Packing 3000pcs/reel

20mA Stable Side View LED SMD 1206 Green 570nm Color Multi Function

Applications:

Products are widely used in various household appliances.electronic products, lighting ornament, digital products,automotive electronics, communications, commercial lighting, indication lighting and traffic light.

20mA Stable Side View LED SMD 1206 Green 570nm Color Multi Function

Materials:

20mA Stable Side View LED SMD 1206 Green 570nm Color Multi Function

Company information:

Dongguan Lanjin Optoelectronics Co., Ltd. established in 2005, a professional manufacturer in producing light emitting diode, LED digital display, SMD LED , through-hole LED and LED PCB assembly service. Covering 2,500 square meters factory plant, with modern purification constant termperature and humidity anti-static production workshop.

Our company has passed ISO9001:2015 international Quality management system certification, and now applying for ISO14001 Environmental management system certification. With 18 years development, we achieved 2 national invention patents, 12 practical new-type patents, 2 software invention patents, all products comply with the EU RoHS standard.

Lanjin has absorbed the advanced manufacturing technology of Japan, Korea and Western Europe. With a high starting point, high quality market positioning, developed high temperature resistance & long life LED. Widely used in communication equipment, swithching power supply, decorative lighting, multi-speaker, DVD and other electronics.

Lanjin always addict to the principle of “ Quality and customer first”, provide customized services according to customer’s demand. LED light the world, Lanjin lights your life!

20mA Stable Side View LED SMD 1206 Green 570nm Color Multi Function

Packing and Shipping:

Inner packaging: Anti-static Bag Vacuo Packaging

Outer packaging: Standard export carton packing.

20mA Stable Side View LED SMD 1206 Green 570nm Color Multi Function

20mA Stable Side View LED SMD 1206 Green 570nm Color Multi Function

FAQ:

Q1: Are you a factory?

A: Yes, we have our own factory in Donguan, if you have time come China, welcome your visisting!

Q2: Could you please send me the free sample, so that I could see and check its quality?

A: Yes. We can send you free samples first, if the value is low. But our clients should pay for the shipping freight themselves. Samples fee needs to be charged if the value is high.

Q3. How do you ship the goods and how long does it take to arrive?

A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-7 days to arrive.

Q4. How to proceed an order for led light?

A: Firstly let us know your requirements or application.

Secondly We quote according to your requirements or our suggestions.

Thirdly customer confirms the samples and places deposit for formal order.

Fourthly We arrange the production.
