10L Centrifugal Spray Dryer Drying Machine For Egg Powder/Tea/Herbal Extract/Protein/Starch
10L Centrifugal Spray Dryer Drying Machine For Egg Powder/Tea/Herbal Extract/Protein/Starch
10L Centrifugal Spray Dryer Drying Machine For Egg Powder/Tea/Herbal Extract/Protein/Starch
10L Centrifugal Spray Dryer Drying Machine For Egg Powder/Tea/Herbal Extract/Protein/Starch
10L Centrifugal Spray Dryer Drying Machine For Egg Powder/Tea/Herbal Extract/Protein/Starch
10L Centrifugal Spray Dryer Drying Machine For Egg Powder/Tea/Herbal Extract/Protein/Starch
Specifications
Brand Name :
Lanphan
Model Number :
LPSD-10
Certification :
contact us
Place of Origin :
China
MOQ :
1 Unit
Price :
$6599/Unit
Payment Terms :
L/C,T/T, Paypal , Western Union, MoneyGram...
Supply Ability :
900 Sets per Month
Delivery Time :
5-7 work days
Packaging Details :
wooden package
Product Name :
Spray Dryer Drying Machine
Air inlet temperature control :
RT~300ºC
Feed Volume :
10000mL/H(adjustable)
Total power :
22KW/380V
Nozzle speed :
36000rpm(adjustable)
Nozzle diameter :
1.00mm
After Warranty Service :
Online service
Drying Time :
According to customer requirements.
Description

High-Speed Centrifugal Spray Dryer Drying Machine For Egg Powder/Tea/Herbal Extract/Protein/Starch

Spray Dryer Drying Machine​ Description

10L Centrifugal Spray Dryer Drying Machine For Egg Powder/Tea/Herbal Extract/Protein/Starch

Spray Dryer Drying Machine Parameter

​10L Centrifugal Spray Dryer Drying Machine For Egg Powder/Tea/Herbal Extract/Protein/Starch

10L Centrifugal Spray Dryer Drying Machine For Egg Powder/Tea/Herbal Extract/Protein/Starch

Working principle: After passing through the filter and heating device, the air enters the hot air distributor at the top of the drying chamber. The hot air passing through the hot air distributor enters the drying chamber evenly and rotates in a spiral shape. At the same time, the liquid is sent into the equipment in the drying chamber and sprayed into high-efficiency droplets through the centrifugal spray head at the top, which greatly increases the contact surface area between the liquid and the hot air. The water evaporates quickly and the finished product is dried in a very short time. The thicker finished product is recovered by the collection tube at the bottom of the dryer, and the exhaust gas is discharged by the centrifugal fan.

Spray Dryer Drying Machine Details

10L Centrifugal Spray Dryer Drying Machine For Egg Powder/Tea/Herbal Extract/Protein/Starch

Spray Dryer Drying Machine Factory

10L Centrifugal Spray Dryer Drying Machine For Egg Powder/Tea/Herbal Extract/Protein/Starch
