Network 1000VDC HDPE Cat6 Lan Cable ETL FTP 4 Pair Shielded CCA Al Mylar
Network 1000VDC HDPE Cat6 Lan Cable ETL FTP 4 Pair Shielded CCA Al Mylar
Network 1000VDC HDPE Cat6 Lan Cable ETL FTP 4 Pair Shielded CCA Al Mylar
Network 1000VDC HDPE Cat6 Lan Cable ETL FTP 4 Pair Shielded CCA Al Mylar
Network 1000VDC HDPE Cat6 Lan Cable ETL FTP 4 Pair Shielded CCA Al Mylar
Network 1000VDC HDPE Cat6 Lan Cable ETL FTP 4 Pair Shielded CCA Al Mylar
Network 1000VDC HDPE Cat6 Lan Cable ETL FTP 4 Pair Shielded CCA Al Mylar
Network 1000VDC HDPE Cat6 Lan Cable ETL FTP 4 Pair Shielded CCA Al Mylar
Specifications
Brand Name :
OEM/ ODM/ LANSAN
Model Number :
CAT6 FTP
Certification :
UL/ CE/ ETL/ ROHS/ ANATEL
Place of Origin :
CHINA
MOQ :
100 Rolls
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union, MoneyGram. Paypal,
Supply Ability :
5000 Rolls/Day
Delivery Time :
15-25 Work Day
Packaging Details :
305 meter/roll
Conductor :
0.57mm CCA
Insulation :
HDPE
Cord :
4Pairs
Shiled :
Al Foil
Jacket :
PVC/LSZH/PE/PVC+PE
Color :
Customized
Use :
Communication
Length :
1000ft/305m
Description

Network 1000VDC HDPE Cat6 Lan Cable ETL FTP 4 Pair Shielded CCA Al Mylar

Description

  • Widely used at Voice data, Graphic image, Multi-media, Security monitoring and other
    data transmission.

  • Combined with keystone Jack Patch cords, and patch panel, it provides
    excellent and stable performance.

  • The solution is for hospital, government manufacturingand other environments.

Specification

No. of Cord 4 Pairs
Conductor Material CCA
Construction 1/0.57 ± 0.008mm
Insulation Material HDPE
Filler /
Shield Material Aluminum Mylar Spirally Wrapped
Braiding /
Drain Wire Material Aluminum Magnesium Metal
Rip Cord Nylon
PE Cross Material Polyethy Lene
Construction 4.4mm*4.4mm
Jacket Material PVC/LSZH/PE
O.D. 6.2 ± 0.2mm
Color Customized
Marking Customized
Mutual Capacitance 5.8nF/100m
Dielectric Test 1000VDC /1 min ; No Breakdown
Temperature Rating 60℃
Operating Temperature -20℃ ~ 80℃
Velocity of Propagation 0.69

Electrical characteristics


DC impedance: 100Ω ±15%, 1 to 250MHz
Transmission delay: 536ns/100m max at 250MHz
Time delay difference: 35ns max/100m
Capacitance: 5.6nF/100m
DC resistance: ≤9.4Ω
NVP: 68%

Execution standard


CPR, ANSI/TIA/EIA-568, CSAC22.2, ISO/IEC11801, YD/T1019-2001

Network 1000VDC HDPE Cat6 Lan Cable ETL FTP 4 Pair Shielded CCA Al Mylar
