P4.8mm 500x1000mm Stage LED Screen Display , Outdoor Led Backdrop Screen
P4.8mm 500x1000mm Stage LED Screen Display , Outdoor Led Backdrop Screen
P4.8mm 500x1000mm Stage LED Screen Display , Outdoor Led Backdrop Screen
P4.8mm 500x1000mm Stage LED Screen Display , Outdoor Led Backdrop Screen
P4.8mm 500x1000mm Stage LED Screen Display , Outdoor Led Backdrop Screen
P4.8mm 500x1000mm Stage LED Screen Display , Outdoor Led Backdrop Screen
Specifications
Brand Name :
Eachinled
Model Number :
P4.8
Certification :
CE,ROHS,UL,ISO:9001
Place of Origin :
Shenzhen,China
MOQ :
6 square meters
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
5000 square meter per month
Delivery Time :
20~25 days
Packaging Details :
flightcase packing, can be customized size
panel size :
500mmx1000mmx75mm
driving ic :
MBI5124
leds :
SMD2727
power source :
G-energy/Meanwell
connectors :
Seetronic/Neutrik
applications :
Outdoor events rental,mobile stage,concerts,wedding backdrops
brightness :
>5500nits
led chip :
Epistar
weight :
14kgs
viewing distance :
>4m
Description

P4.8mm 500x1000mm Stage LED Screen display , Outdoor led backdrop screen
Advantage of LED Mesh screen for Stage and Rental
1.Light weight: it can be loaded by one person, quick assemble,maintain,save labour costs
2.Thin cabinet: the thickness is only 75mm,the space of the screen is small,and the entire screen will be more beautiful.
3.Flat screen: smooth surface error is under 0.1cm, it can remove the mosaic phenomenon effectively.
The effect of the display will be more clear and exquisite.
4. Quick dismounting: adopt fast locking structure connected, flat and beautiful background.
5. Low release heat: low noise,low consumption,excellent thermal design and excellent thermal dispersion
Specifications for P4.81,5.95 outdoor rental led display screens

Items Parameter
Pixel Pitch PH4.81mm PH5.95mm
Panel Resolution(W*H) 104(W)*208(H) 84(W)*168(H)
Pixel Configuration 1R1G1B( 3 in 1)
LED Encapsulation Black SMD 2727 SMD 3535(white&black)
Pixel Density 43264 dot/m2 28224 dot/m2
Driving Method 1/13 Scan 1/7 Scan
Refresh Frequency ≥1920Hz ≥1920Hz
Driver IC Special constant current IC with high refresh rate & high grey scale
Grey Scale 14Bit(depending on the system and IC configuration)
Cabinet Size 500mm*1000mm*75mm
White balance Brightness ≥5500cd/ m2 ≥5500cd/ m2
Color Temperature 8000K±500 (adjustable)
Viewing Angle Horizontal 140 Vertical 120
Optimal Viewing Distance ＞5m ＞6m
Working Voltage AC 220V/110V ±10%
Module voltage DC4.2V
Max Power Consumption 800W/PCS 800W/PCS
Avg.Power Consumption 300W/PCS 300W/PCS
Lifetime 100000hours
Operating Temperature –10C ～65℃
Net weight 14Kg/pcs 14Kg/pcs

Detail cabinets show
P4.8mm 500x1000mm Stage LED Screen Display , Outdoor Led Backdrop Screen

This Universal cabinet lock is popular using for rental led cabinet display, operate very easy, lock very flat, no mosaic,up and down each sides with two locks,easy and quick install and save labour cost.
P4.8mm 500x1000mm Stage LED Screen Display , Outdoor Led Backdrop Screen
Aging testing to inspect color,pictures and videos before shipping
P4.8mm 500x1000mm Stage LED Screen Display , Outdoor Led Backdrop Screen
Packing, common package is 6pcs in 1 flightcae, can be customized of wooden case packing
Company introduce and our service
1)Reply your enquiry of led display in 24 working hours.
2)Experienced staffs answer all your query in fluent English,Spanish,French,etc
3)Customized design is available,OEM & ODM are welcomed.
4)Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staffs.
5)Special discount and protection of sales area provided to our distributor.
6)Warmly welcome your visit in our company if available.
7)Warranty: 24 months, a little investment for longer warranty time.
