HD TV Station Led Display Screen Led Video Wall for Live Broadcast
1) Price Advantage: we have the best competitive price at the market, also have the same even better quality.
2) Quality advantage: From material to finished product, from design to produce, we control all steps
3)Built specially for the demanding rental and staging applications, 3.91mm LED system for indoor AV rental use: easy and fast installation and unrivalled reliability.
4)The ultra-thin design, die-casting aluminum structure, light weight, wide viewing angles, superb color uniformity across entire surface of the display.
5)High refresh rate ensure no flicker for live videos and fast pictures. High resolution creates great visual impact even at very short viewing distance.
6)Add to the above listed features that enable P3.91 LED display as a preferred option for high-end indoor audio visual screens.
Technical Specification:
Pixel Pitch | 3.9mm | 4.8mm | 5.2mm |
LED type | RGB 3in1 SMD2121 | RGB 3in1 SMD2121 RGB 3 in 1 SMD3528 | |
Pixel Density(dot/s.q.m) | 65536 | 43402 | 36864 |
Resolution(WxH) | 128*128dot | 104*104 dot | 96*96 |
Cabinet size | 500x500x80mm | ||
Weight | 8kg | 8kg | 8kg |
Waterproof rate | IP43 | ||
Brightness | 1200nits | 1200nits | 1500nit |
View Distance | 3m | 4m | 5m |
Viewing Angle (H/V) | 140°/120° | ||
Gray Scale | 16bit | ||
Color type | 68 Billion | ||
Max.Power Consumption | 250W/PCS | 120W/PCS | 110W/PCS |
Ave .Power Consumption | 130W/PCS | 60W/PCS | 45W/PCS |
Refresh rate | 1960Hz | ||
Gamma | -5.0~+5.0 | ||
Applied environment | INDOOR | ||
Controller | Synchronous display with control PC by DVI | ||
Support Input | Composite ,S-Vide ,Component ,VGA,DVI,HDMI,HD_SDI | ||
Power input | AC 110-220V±10% | ||
Environment | temperature -10°C~+50°C,humidity 10~90% RH | ||
Operating Life | 50,000hour |
EachinLED LED Screens are easy to build a dynamic and engaging LED Video Walls that will attract attention. Brilliant images, superior color grayscale performance and low noise design satisfy informing and interacting with conference participants. The unique mechanical structure of EachinLED LED screen realizes versatile installation and quick setup, which make your investment cost-effective.audio visual equipment rental
FAQ
Q1: What's the pixel pitch for Indoor LED Display Screen ?
A1: Indoor (3.9mm / 4.8mm/5.2mm/5.95mm/6.944mm)
Q2: Where is it used for?
A2: Indoor & rental use. Widely used for backdrop of staging event, rental business, liveshow, concert, etc.
Q3: Can it play HD video?
A3: Yes, it can realize HD video function with Novastar controlling system.
Q4: What's the controlling system?
A4: Our standard controlling system for this model is Novastar. Also support other controlling system, like Linsn, etc.
Q5: How about the size of project?
A5: Please offer the size with "width by height" of project. We wil offer the suitable solution for your project size. I will appreciate it if any drawing files about installation offered.
Our Service
In-sale service:
1. Tracking report in producing.
2. Quality test report for every order.
3. Photos and videos as per customer's requirement.
4. Free spare parts.
After-sale service:
1. Lifetime free maintenance and upgrade.
2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
3. Customer satisfaction tracking report.
4. Free technician training.
5. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on.
6. Special service for big project, such as stadium, exhibitions, squares and so on.
