Nationstar SMD Outdoor Rental LED Display 110-220 1/16 Scan Outdoor Display LED
Nationstar SMD Outdoor Rental LED Display 110-220 1/16 Scan Outdoor Display LED
Nationstar SMD Outdoor Rental LED Display 110-220 1/16 Scan Outdoor Display LED
Nationstar SMD Outdoor Rental LED Display 110-220 1/16 Scan Outdoor Display LED
Specifications
Brand Name :
Eachinled
Model Number :
P3.9
Certification :
CE Rohs IOS9001
Place of Origin :
China
MOQ :
2 square meters
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
1000 Square meters Per Month
Delivery Time :
5 days
Packaging Details :
Plywooden Case or Flight Case/Road Case
Cabinet Size :
500mm*500mm
Module size :
500mm*125mm
Weight Of Cabinet :
8.5kg
Driving Metho :
1/16 Scan
Brightness :
5000 Nit Per Square Meters
Led encapsulation :
Nationstar SMD1921
Application :
Party, wedding, concert, tour, fashion show,events
Description

Nationstar SMD Outdoor Rental LED Display 110-220 1/16 Scan Outdoor Display LED

Product Description:

1. Multifunctional:

The screen use for different kinds of event, such asParty, wedding, concert, tour, fashion show. And it also could be put on the floor as dance floor.

2. Curved design is available:

The screen could be curved, inner and outer curved +-15°.

3. Cabinet edge protection design:

The bottom modules on the cabinet are about 5mm off the round. So they will not be hit when we put the cabinets on the ground. This will greatly protects the LEDs from damage during assembly and disassembly.

4. Ladder function:

The cabinet is with strong rack, which could be used as a ladder to climb up for maintenance.

5. Quick and more secure assembly:

Only 2 steps to lock the cabinets together, one person can finish installation 12sqm within 2 hours.
Technical Specifications:

P3.9 Outdoor Rental LED Display 4 by 3 Meters
Module Pixel Pitch P3.91mm
Module size 500mmx125mm
Density of pixel/(dots/m2) 65536
Led encapsulation SMD1921
Resolution of module 128X32 dots
Main Optimum viewing distance 3.9m
View angle / ° 140 H,120 V
Max power consumption/W/M2 750
Size of cabinet/mm 500X500
Resolution of cabinet 128x128
Weight of cabinet/kg 8.5
Driving method 1/14 scan constant current
Refresh rate Hz/S ≥3840
Luminance of white balance ≥5000 nits
Waterproof rate IP65
Working vlotage 110-220 VAC/+/- 10%
Input signal RF,S-Video,RGB,RGBH,YUV,YC&Composition ,etc
Control system Novastar(sending card,receiving cards and Hubs)
Life span >100,000h

Detail Product Pictures:

Weight & Dimensions
Panel Dimensions: 500×500×65mm
Panel Weight: 8.5kg
Module Dimensions: 500×125mm

IC:ICN2053

Nationstar SMD Outdoor Rental LED Display 110-220 1/16 Scan Outdoor Display LED

In order to make your purchasing more easy, we provide dual use hanging beam and support

structure for your different events use.

Waterproof Outdoor Rental LED Screen in Sweden

Nationstar SMD Outdoor Rental LED Display 110-220 1/16 Scan Outdoor Display LED

WHAT SIZE OF LED SCREEN CAN YOU PROVIDE?
LED screens are made up of panels of 500mm by 500mm. Though screen of any size could be made

by adding panels together,
most common size screens are :

24 Panels 4m by 3m

40 Panels 5m by 4m
48 panels 6m by 4m

Choose an LED Screen with a pixel pitch (resolution) that suits your need.Example :2.97mm 3.91mm.

4.81mm. 5.95mm

Our Team:

Nationstar SMD Outdoor Rental LED Display 110-220 1/16 Scan Outdoor Display LED

How Contact Us:

Email: suki@eachinled.com

Whatsapp:+8613632391442

Skype: strawberry935200

http://www.linkedin.com/in/suki-lau-500279141/

If you are interested, pls add my whatsapp for more detailed pictures and video!
