Specifications
Brand Name :
Eachinled
Model Number :
P3.9
Certification :
Rohs CE
Place of Origin :
Shenzhen China
MOQ :
6 square meters
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
5000 Square meters Per Month
Delivery Time :
15 Days
Packaging Details :
Wooden Case and Flight Case/Road Case
Refresh rate: :
2500hz
Display Function :
Indoor stage led video wall
Weight of Cabinet :
8kg
LED Constitute :
SMD2121 Black LEDs
Driving Method: :
1/16 scan
IC :
MBI5124
Power Supply :
AC110-220V
Cabinet Material :
Die Casting Aluminum
Brightness :
1000-1200 nit per sqm
Operating Life: :
>460000hours
application :
AV indoor led video wall
Description


Super Stage Led Screen , Video Productions Indoor Led Video Wall Lightweight

1.Die casting Aluminum panels is stronger structure, each panel is 8.5kg,very light weight to carry and install .Even after long time, the LED screen won't change shape under pressure.

2. Good cabinet size of 500x500mm to make easy calculation, and highly raise the safe of the screen installation, humanization designed cabinet ensured fast assemble and dismantle it is convenient for one person to handle one cabinet, save time and labor costs.

3. P3.9 Led video wall of cabinet is new design, Private Model, which mean other company don’t have same cabinet, it is unique. In addition, a lot of Led display manufacturer offer P3.9 cabinet is public model with cheaper, but maybe not have a good guarantee and reputation.

4.New design without fans, no noise and lower consumption with handlebar. We can print your logo or company name on our cabinet and flight case for free.

5.Good and easy way to replace broken led module with 10 seconds.

Technical Specification:

Part Number

I-P3.9

I-P4.81

I-P5.2

I-P5.95

Pixel Pitch

3.91mm

4.81mm

5.21mm

5.95mm

Pixel Density

65536dot/m2

43264dot/m2

36864dot/m2

28224dot/m2

Resolution

128x128dot

104x104dot

96x96dot

84x84dot

LED Configuration

SMD 2121

SMD 3528

Brightness

1000-1200CD/m2

1000-1200CD/m2

1500-2000CD/m2

1100-1400CD/m2

View Distance

>4m

>5m

>5m

>6m

Scanning Mode

1/16

1/13

1/8

1/8

Display Scale

16.7M

16.7M

16.7M

16.7M

Max.Power Consumption

600W/m²

600W/m²

500 W/m²

450 W/m²

Ave.Power Consumption

300 W/m²

300 W/m²

250 W/m²

225 W/m²

Refresh Frequency

≥2000HZ

≥2000HZ

≥2000HZ

≥2000HZ

Cabinet Size

500mmx500mmX80mm

Cabinet Weight

6kg

IP Rating

IP43

Viewing Angle (H/V)

140°/120°

Gray Scale

14-16bit

Brightness Adjustment

8 levels adjustable

Gamma Correction

-5.0~+5.0

Environmental

INDOOR

Control Mode

Synchronous display with control PC by DVI

Support Input

Composite,S-Video,Component,VGA,DVI,HDMI,HD_SDI

Operation Power

AC100~240 50/60HZ

Operating Temperature

- 20℃~+50℃

Operating Humidity

10~95% RH

Operating Life

≥50,000hours


Super Stage Led Screen , Video Productions Indoor Led Video Wall Lightweight
Super Stage Led Screen , Video Productions Indoor Led Video Wall Lightweight
How can you prove to rental business company that a large LED screen will be more profitable for them than a traditional stage equipment?”
Eachinled will give your answer.
Eachinled product includes LED Stage display ,HD LED Video Wall,Concert Led Screen, Indoor LED display, Outdoor LED Display Screen, Curtain LED Display, LED board, LED Signs, Outdoor LED panel, full color led screen, LED sign, led screen board, outdoor led panel, indoor led screen etc

Every event is special and you only get one chance to deliver your message - Let us assist you

FAQ
Q1: How to choose a proper led screen for your need?
A1: You just need to know the answers of 3 simple questions.
❶. Will you use it indoor or outdoor(waterproof and brightness)?
❷. Is it for rental use(need to be moved from one place to another place very often) or for fixed installation( to be installed in one place forever)?
❸. What is the approximate size of the led screen you would like to purchase?

Q2:How long is the guarantee period?
A2: All kinds of our LED display screen here we offer 2 years at least warranty.

Q3: How is the payment?
A3: We accept 30% first as deposit for production, 70% balance must be paid before Shipment.
lay screen here we offer 2 years at least warranty.

Our Service and Mission
Eachinled has a perfect service system for our customer.
The measure of success for any business is how they are viewed by their clients. In our years of supplying indoor and outdoor LED screens to the customers across the world, we have received exceptional feedback and many regular clients find us over and over again for all their led screen needs.

How Contact Us
Email:winni@eachinled.com
Whatsapp:+8618320837541
Skype:winni_158
